Features:

Adopts Embedded RTOS design,32bit DSP CPU, Integrated high performance video encode accelerator, Super high performance RTOS

Dual stream,Video code rate (64kbps-8Mbps) can be uninterrupted adjust

Support video loss, Motion Detection, Probehead alarm

Support TCP/IP, support IE browser/Android/iOS etc.

Bi-direction audio,RS485,Alarm,POE,USB,TF port, Analog video output port(BNC) etc. Optional

Adopts double glass, the image more clear and bright

Built-in double IR-CUT filter, No color deviation

Adopts Long-life and SMART 30pieces 5 IR Leds, IR range up to 30meters

3.6mm/F1.2 Megapixel lens, 6mm,8mm/F1.2 optional

Metal housing,Vandal proof

Specification:

Model

DLX-IDV20

DLX-IDV40

DLX-IDV50

Sensor

1/2.8" CMOS

1/2.5" CMOS

1/2.5" CMOS

Horizontal Resolution

2Mp

4Mp

5Mp

Signal System

PAL/NTSC

Lens

Fixed 3.6mm/F1.2 Megapixel lens (6,8,12,16mm/F1.2 optional)

Min. Illumination

0LUX(IR on)

IR

30pieces 5 IR LEDs, IR range 30M

BLC

Auto

WDR

Digital

AGC

Auto

Electronic shutter

1/50(1/60)s to 1/100,000s

S/N

>80dB

Gamma correction

>0.45

Ethernet port

1 RJ45 Ethernet port,10/100M

Video process

H.265 code, Dual Stream, AVI format, 64k~8Mpbs adjustable

Protocol

ONVIF, RTSP,PPPoE,DHCP,TCP/IP,HTTP,UDP,RTP/RTCP,UPNP,FTP,DDNS

Power

DC12V 10%

Material

Metal

Operating Conditions

-18 C - 50 C, Humidity 90% or less (non-condensing)

Dimension

130x100mm

Weight

500g
