Special Feature

High light LED display

 Metal frame, with plastic spray technique and lasting

Independent Anesthesia Ventilator, could be driven by medical air

 Classical Flowmeter of 2 tubes

 Integrated Circle Absorber, classical and practical

 Working Mode:

   Semi-open, Semi-closed or Closed system

 Gas Supply Pressure

   O2: 0.27Mpa-0.55Mpa

   N2O: 0.27Mpa-0.55Mpa

Flow meter

2 Tube: 1 x O2 Tube, 1 x N2O Tube

O2 Tube: 0L/min-10L/min

N2O Tube: 0L/min-10L/min

O2 and N2O Linkage Device, keep oxygen concentration not lower than 25%

Oxygen flush: 25L/min-75L/min

Safety Function

When airway pressure reach 6 kPa,  APL valve will automatically release gas

 When airway pressure reach 6 kPa, the Bellows will stop sending gas to patient

 Monitoring parameters (under Manual and Ventilation):

    Tidal Volume

Minute Ventilation

I:E ratio

Alarm parameters (Audible and/or visual signal):

Tidal volume high/low limit

Minute Ventilation high/low limit

Low O2 Supply Pressure (when O2 Supply Pressure is lower than 0.15Mpa,  will arouse Audible Alarm)

N2O automatic Cut off Alarm

Anesthesia Ventilator

 Respiration mode: IPPV, Manual

 Tidal Volume: 50-1600ml

 Respiratory frequency: 1-90 bpm

 I:E ratio: 4:1-1:6

Anesthesia Vaporizer

 Economic Anesthesia Vaporizer

 Fixing with Anesthesia Machine

 Agent: Isoflurane, Enflurane for choice

Electrical Specification

 Mains: 100-240V, 50/60Hz Power consumption: 50W

Dimensions Size: 78*50*128cm

Optional

Anesthesia Ventilator TH-1(A) Anesthesia Vaporizer Eagle2000
