Tan Delta Tester

Capacitance range: Internal HV:    3pF-60000pF/10kV       60pF-1F/0.5kV

External HV: 3pF-1.5F/10kV             60pF-30F/0

Resolution: Maximum 0.001pF, 4 valid figures.

Tg range:unlimited, 0.001% resolution, automatic identification for Capacitance, inductance and resistance of three tested articles.

Test current range: 10A-1A

Internal HV: Set voltage range: 0.5-10kV

Maximum output current: 200mA

Buck-bust method: continuous stepless regulation

Test frequency: 45, 50, 55 single frequency  45/55Hz automatic dual variable frequency

External HV: in case of UST, maximum test current is 1A, and power frequency or variable frequency is 40-70Hz

in case of GST, maximum test current is 10kV/1A, and power frequency or variable frequency is 40-70Hz

CVT self-exciting low voltage output: Output voltage 3-50V, output current 3-30A

Measuring duration: about 40s, depending on measuring method

Input power supply: 180V-270VAC, 50Hz/60Hz1%, supplied by alternating current or generator

Computer interface: Standard RS232 interface

Printer: WH-A7 mini-type thermal printer

Environment temperature: -10-50

Relative humidity: <90%

Overall dimension:460360350mm



Capacitance and Tan Delta Tester Weight:28kg
