| Rated Power: | 25kva |
|---|---|
| Frequency: | 50HZ 60HZ |
| Speed: | 1500turn 1800turn |
| Output Type: | AC Three Phase |
| Brand Name: | cummins |
| Rated Current: | 36A |
| Rated Voltage: | 400/230V |
| Model Number: | 25GF |
| Place of Origin: | China (Mainland) |
| color can be selected: | Black, green, red and yellow |
Quick Details
Specifications
Product Description
the Specification of 20kw deisel generator:
50HZ,400/230V,3P 4W |
Genset Model |
20GF |
Prime power |
20kw/25kva | |
Standby power |
22kw/27.5kva | |
Overall Size(mm) |
1840*760*1430 | |
Gross Weight(kg) |
800 | |
Cummins Diesel engine |
Model |
4B3.9-G1 |
Rated Power |
24kw | |
Intake type |
Natural | |
NO. of Cylinder |
4.L | |
Bore*Stroke(mm) |
102*120 | |
Compression Ratio |
16.8:1 | |
Rated fuel Consumption(L/h) |
6.7 | |
Displacement |
3.9 | |
Stamford Alternator |
Model |
PI144E |
Rated power |
20kw/25kva | |
Power Efficiency |
85.80% | |
Voltage Regulation |
1.5 | |
Excitation Type |
Brushless | |
Insulation Class |
H |
the ENGINE SPECIFICATION of NEW MODEL GENERATOR DIESEL 20KW by CUMMINS ENGINE
Model |
4B3.9-G1 |
Rated Power |
24KW |
Cooling Method |
Water cooled |
Rotating Speed |
1500/1800rpm |
Governor System |
electrical or mechanical governor |
Aspiration Mode |
turbocharged |
Starting Method |
12V electric starting |
Stroke |
4 stroke |
the SPECIFICATION of ALTERNATOR for NEW MODEL GENERATOR DIESEL 20KW by CUMMINS ENGINE
Brand |
COPY STANMFORD |
Rated Power |
20KW/25KVA |
Regulator |
AVR Automatic Voltage Regulating |
Excite Type |
Pret or Shunt |
Connecting Type |
3PH star, 3PH-DELTA |
Steady Frequency Change |
0-5% |
No Load Voltage |
95%-105 |
Steady Voltage |
1 |
Insulation Degree |
H degree |
Exclosure Degree |
IP23 |
Our Services
Warranty policy of power generator set:
Guarantee for one year or 1500 hours whichever reach first from ex-factory date.
during the guarantee period, we will provide the free easy-damageable
Spare parts of diesel engine caused by our quality of production or raw material.
after expiration, we provides cost spare parts maintenance of gensets
