Main Features:

Split structure and ready repair kit for Easy maintenance and repair.

Double imported high-precision ball Bearings for high stability.

Balanced mechanical sealing structure for Prolonged service life.

Standard Sic/Carbon Graphite sealing pair for good sealing performance.

Optional Sic/Sic, Tungsten carbide/Tungsten Carbide and other sealing pairs for strict environment.

Standard SUS304 end cover and SUS304 rotor for prolonged operation.



Technical Ratings

     Max Speed:3000 r/min

     Temperature:-30+120

     Max Pressure:1.1Mpa

     Media: Water

Operation under extreme ratings should be Avoided. Please follow the" Nominal Diameter/Speed Check List", or please Consult AIKE SEALING for safety operations.



Notes:

1.Please make sure one drainage hole is Vertically downwards.

2.Vertical installation is prohibited, as the bearings are prone to be corroded by leakage from the sealing surface.

3.the rotary joint must not be used to Carry explosive, inflammable, poisonous and highly corrosive medium.

4.for dual flow stationary type, the " S" Thread is RH (right-thread).

5.for other application, please consult AIKE SEALING beforehand.
