JUNSUN ZYD Series High Quality Mobile Type Transformer Oil Treatment Plant equipped with trailer and cover is specially designed for treating transformer oil and other kinds of insulating liquids.

Transformer oil maintenance is the key to transformer reliability, performance and longevity. Your transformer's insulating oil should be free from moisture, dissolvedgases and particles that accumulate as the oil ages. Evensome new oils may require treatmentto limit these contents to acceptable levels.

JUNSUN are a designing, engineering and manufacturing company capable of application customization for best solutions.

Water Removal: Overall Water Content 5 PPM by removing free, emulsified, and dissolved water

Particulate Removal: Particle counts as low as 1 micron.

Entrained Air and Gas Removal  0.3%

Acid Removal: can be equipped with fullers earth towers to neutralize acid and Lower TAN to < 0.03 KOH/g

Dielectric Strength :70 kV per ASTM 877



1. Two separating house made by stainless steel. Oil flow by rotation in stereo evaporation to degas and dehydrate well.

2. the combination of axial fan and condenser make vapor from vacuum pump and roots pump into water, it can prolong time to change vacuum oil while meet emission standard.

3. Multiple Filter Housings with Cartridge Style Filter Elements, big filtering area to hold more particles.

4. Control system: IEC standard with each wire marked.

5. Oil level in vacuum tank is controlled by photoelectric switch, which is flexible and accurate. No oil-spraying.
