Technical Feature

Unit

Result

Material Features

Frontplate Material

Bayer PC

Base Material

Bayer PC

Protect Door material

DuPont PA66

Socket Copper slide

Phosphor bronze

Electrical Features

Rated Voltage

V

250(DC~5V)

Rated Current

A

13A(2.1)

Rated Frequency

Hz

50/60

Creep Distance

mm

3

Electric Clearance

mm

3

Earthing Protection,12VAC, 25A

0.2

Insulation Resistance, 500VDC, 1min

5M

Temperature Rising, 22A, 1hour

K

45

Mechanical Features

Distance between plug and surface of socket

mm

1

Mechanical Intensity, punching test

5times, 100mm

Mechanical Life, power socket

Times

10000

Mechanical Life, USB charg port

Times

00

Protection Grade

IP20

Fireproof, 850of glowing filament

S

15

Heating Resistance, 702

168hours

Ambient Temperature

-5~~40

Storge Temperature

-25~~70

Installation Features

Terminal Connect type

Cable/Pin-type Busbar

Terminal Size top/bottom for cable

mm2

2.5

Installing Screw hole distance

mm

602

Pulling Force for screws

N

50
