| Brand Name: | Securina |
|---|---|
| Color: | white |
| mesh size: | Tunnel Size: 600mm 400mm |
| Mesh wire diameter: | Conveyor Speed: 0.22m/s |
| Geotextile: | Conveyor Max Load170kg |
| Model Number: | SA6040 |
| Place of Origin: | China (Mainland) |
| Technical Principle: Dual-energy X-ray Imaging: | L Shaped Array, |
| Spatial resolution: | Level: Dia1.0mm, Vertical: Dia1.3mm |
| Penetrate resolution: | Dia 0.511mm |
Quick Details
Specifications
X Ray Baggage Scanner Security Inspection Explosive Detection Equipment SA6040
Securina SA6040 the user-friendly delivers best-in-class speed and detection capability and makes the most of available space. this single-source, dual-energy system is designed to screen small- to MID-sized items for weapons, explosives, drugs and other contraband. The right size for scanning strollers, briefcases, backpacks, purses and other hand-carried items, this compact workhorse is ready to meet the toughest throughput demands.
Securina SA6040 X-ray system's low profile, bottom-up generator design makes fine lines appear much sharper and larger on-screen. with a trim footprint, the user-friendly SA6040 delivers best-in-class speed and detection capability even where space is limited.
Securina SA6040 is ideal for screening at checkpoints and building entrances, train stations, Staff & Visitor Checkpoint Inspection, Corporate, Government & Private Security, Critical Infrastructure Security, Mail Screening
General Specifications:
| Tunnel Size | 600(W)*400(H)mm |
| Conveyor Speed | 0.22m/s |
| Conveyor Max Load | 170kg |
| Dose per Inspection | <2.9 Gy/h |
| Resolution | <0.101mm Metal Wire |
| Spatial resolution | Level: Dia1.0mm, Vertical: Dia1.3mm |
| Penetrate resolution | Dia 0.511mm |
| Penetration | 30-32mm steel |
| Film Safety | Guarantee ISO1600 Film |
| X-ray Leakage | <0.5 Gy/h (at a distance of 5cm from external housing) |
| Image System: | |
| Technical Principle | Dual-energy X-ray Imaging; L Shaped Array |
| X-ray Sensor | L-Shaped Photodiode Array (multi-energetic) |
| Monitor | High Resolution Color, LCD Accord, 17inch |
| Image Display | High resolution of 1024 * 1280 pixel; Image Grey Level: 65536 |
| Image Enhancement | 1-64times enlargement continuity, Color/BW, negative, high/low Penetration, organic /inorganic Stripping, general enhancement, and pseudo color, etc. |
| Image Recall: | All preceding images recallable, retrieval. |
| Explosives & Narcotics Detection | Explosives & narcotics alarm and highlight according to atomic number signature |
| High Density Region Alarm | Impenetrable region alarm and highlight, for possible concealing of Threats and contrabands |
| Image Archive | up to 100,000 images stored automatically, enable transferring to USB disk, and Converting to JPG, BMP and other general formats |
| Miscellaneous Functions | Time/date display, counters, user management, system-on/X-ray-on Timers, power on self test, built-in diagnostic facilities, dual-direction scanning, system log, system standby and stimulant training,etc |
| Network Applications | Multiple remote applications available based on Ethernet LAN and Windows platform, such as image centralized storage and identify, recheck workstation, and network TIP, etc ( Optional). |
| Images process | 24bit real time processing,4colors analysis, Images displayed marked date and ID NO,Count the number of bags,Memory gray level:65536 |
| Operating Environment: | |
| Operation temperature/Humidity | 0C-40C/10%-95%(non-condensing) |
| Storage Temperature/Humidity | -20Cto 60C/ 5%-95%(non-condensing) |
| Operation Power | 220VAC(10%)503Hz (Optional: 100VAC,110VAC,120VAC,200VAC) |
| Power Consumption | 1.0KW (max), 0.7KW(working) |
| Noise | <58db |
| Scanner Dimensions (LWH) | 2007.5mm x868mm x1314 mm |
| Gross Weight | 600kgs |
| Packing Volume | 3.5 CBM |
| X-ray Generator: | |
| Anode Voltage | 140kv |
| Anode Power | 0.35 MA |
| Generate angle | 80 degree upward |
| Brand | Chinese Brand |
| Generate direct | from bottom to top |
| Cooling / Duty Cycle | Oil Cooling /100 |
