1. the featuresof

the drilling rig adopts the automatic Telescopic style with two high strength oil cylinder support, a set of hydraulic valve control rigs operating supine, which is time-saving, safe and reliable to maximize the benefits for users.

the chassis adopts rubber track, light weight and low life cycle cost, which can reduce noise of vehicle running mechanism, reduce car body vibration, and reduce fuel consumption greatly. It can walk on urban roads without hurting the road surface.

the chassis is equipped with four high strength threaded legs (or hydraulic high leg). the installation and adjustment is fast and convenient. It can be used for leveling of work plane, loading and unloading vehicle, which reduces the hoisting cost and improves efficiency and works as auxiliary support.

the drilling rig uses

2. Technical parameters of

Drilling depth	130m
Maximum opening diameter	220mm
Diameter of the end hole	75mm
DrilliNg rod caliber	50mm
Drilling angle	90-75
	2600kg
Spindle
Spindle speed	142/285/570 r/min
	450mm
Windlass
Max single line hoisting capacity	1600kg
Single line lifting speed	0.41/0.82/1.64 m/s
Drum diameter	140mm
	13mm
Wire rope capacity	27m
Type	Horizontal single urn twin-action
Displacement	95/77L/min
Maximum pressure	1.2mPA
Work pressure	0.7mPA
	30mm
Water to exit caliber	20mm
	B1575mm
