After-sales Service Provided: | Overseas third-party support available |
---|---|
Brand Name: | HuaxiaMaster |
Power Type: | Diesel |
Type: | Core Drilling Rig |
Condition: | New |
Warranty: | 6months |
Certification: | iso9001 |
Weight: | 975KG |
Power(W): | 22hp |
Model Number: | HZ-200YY |
Place of Origin: | China (Mainland) |
Application: | general investigation and exploration |
Quick Details
Specifications
1.Applications of
river levees, civil water wells and ground temperature central air-conditioner.
2.Features of
the highest speed can reach 1045r/min with 5 gears, which improves drilling efficiency
adopted 53*59 drilling rod, which has high rigidity and strong delivery torque.
equipped with taper clutch, made the machine easy to operate and free of maintenance.
using large module planetary gear and adding supporting frame, which highly increased hoisting and braking ability of the winch.
.
3. Technical parametersof
300mm | |
End hole diameter |
75mm |
Drill rod diameter |
60mm |
90 | |
Drill weight (without power) |
975kg |
B950 * 4; B1700 * 3 | |
MainDrilling rig moving distance |
300mm |
Power |
Diesel engine 22HP |
Electric motor 15kw | |
Spindle | |
Spindle speed |
64/128/287/557r/min |
450mm | |
Hoist | |
Max. Lifting capacity |
2400kg |
Single line lifting speed |
0.41/0.82/1.64 m/s |
Wire rope diameter |
13mm |
Wire rope length |
35m |
Reel diameter |
140mm |
260mm | |
Hug floodgate belt width |
70mm |
Mud pump | |
Type |
Horizontal single-urn twin-action |
Displacement |
Diesel engine 170L/min |
Electric motor 150L/min | |
Maximum pressure |
3mpa |
1.5mpa | |
Inlet pipe diameter |
40mm |
Outlet pipe diameter |
30mm |
B1728mm |
