Compatible Cisco 1490Nm Dual Fiber Sfp Switch Vcsel Style

up to 1.25G data links

VCSEL laser transmitter and PIN photo-detector

Hot-pluggable SFP footprint

Duplex LC/UPC type pluggable optical interface

Low power dissipation

Metal enclosure, for lower EMI

RoHS compliant and lead-free

Single +3.3V power supply

Compliant with SFF-8472

Case operating temperature

       Commercial:0C to +70C

       Extended:-10C to +80C

       Industrial:-40C to +85C



APPLICATIONS

Switch to Switch Interface

Fast Ethernet

Switched Backplane Applications

Router/Server Interface

Other Optical Links





PRODUCT DESCRIPTION

SFP-1.2-85G-1490nm-120KM-MM-LC-DDM Small Form Factor Pluggable (SFP) transceiversAre compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA). the transceiver consists of four sections: the LD driver, theLimiting amplifier, the 1490nm VCSEL laser and the PIN photo-detector.the module data link up to 120Km in 50/125um multi mode fiber.



the Optical output can be disabled by a TTL logic high-level input of Tx Disable. Tx Fault is provided to indicate that degradation of the laser. Loss of signal (LOS) output is provided to indicate the loss of an Input optical signal of receiver or the link status with partner.
