Features:





Technical details:

Display Technology: DMD

LED Power : RGB LED

Aspect Ratio : 16:9

Effective focal Length : 6.5mm

Focusing : Manual focus in sliding adjustment

Keystone correction : Vertical: 45 degree

Projection distance : 0.5 m to infinite

Image Size :37.8"@ 1m

Offset : 100%

Throwing ratio : 1.4

Contrast : 500:1

Distortion :1.5%

Contsistency(JBMA) : 80%

Color saturation : 100% NTSC

LED life : 10,000 hours

Working Temperature :0 ~ 35 o C

System Parameters

System: Android 7.1

Program : RK 3128 Octa core ARM Cortex-A53 CPU up to 2GHz (DVFS)

CPU : ARM Mali-T820MP3 GPU up to 750MHz (DVFS)

Ruining memory: 2G

ROM : 16G/32G

WIFI :2.4G/5G Wifi

Bluetooth :BT 4.0

Internet :Ethernet  10/100M



Basic parameters

Inbuilt battery Capacity :12V 3.0A/h

Remote Control :Support(IR) Infrared

Screen Mirror:Eshare/iMirror/Miracast

office software: WORD/EXCEL/PDF(Depends on APK install)

Vidoe /Pic Decoding :o  VP9-10 Profile-2 up to 4Kx2K@60fps

o  H.265 HEVC MP-10@L5.1 up to 4Kx2K@60fps

o  H.264 AVC HP@L5.1 up to 4Kx2K@30fps

o  H.264 MVC up to 1080P @60fps

o  MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496)

o  WMV/VC-1 SP/MP/AP up to 1080P@60fps

o  AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps

o  MPEG-2 MP/HL up to 1080P@60fps (ISO-13818)

o  MPEG-1 MP/HL up to 1080P@60fps (ISO-11172)

o  RealVideo 8/9/10 up to 1080P@60fps

o  WebM up to VGA

o  Multiple language and multiple format sub-title video support

o  MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918)

o  Supports JPEG thumbnail, scaling, rotation and transition effects

o  Supports *.mkv,*.wmv,*.mpg, *.mpeg, *.dat, *.avi, *.mov, *.iso, *.mp4, *.rm and *.jpg file

Interface

AC:100-240V,50/60Hz;  DC:12V/3A

Max 32G

HDMI Input

USB 2.0

10/100M

Audio output, 3.5mm joint (can connect with earphone or speaker box)





Package:
