Features:





Technical details:

Display Technology: DMD

LED Power: RGB LED

Aspect Ratio: 16:9

Effective focal Length: 6.5mm

Focusing: Manual focus in sliding adjustment

Keystone correction: Vertical: 45 degree

Projection distance: 0.5 m to infinite

Image Size:37.8"@ 1m

Offset: 100%

Throwing ratio: 1.4

Contrast: 500:1

Distortion:1.5%

Contsistency(JBMA): 80%

Color saturation: 100% NTSC

LED life: 10,000 hours

Working Temperature:0 ~ 35 o C

System Parameters

System: Android 7.1

Program : RK 3128 Octa core ARM Cortex-A53 CPU up to 2GHz (DVFS)

CPU: ARM Mali-T820MP3 GPU up to 750MHz (DVFS)

Ruining Memory: 1G

ROM: 8G

WiFi:2.4G/5G WiFi

Bluetooth:BT 4.0

Internet:Ethernet  10/100M



Basic parameters

Inbuilt battery Capacity:5V 3.0A/h

Remote Control:Support(IR) Infrared

Screen Mirror:Eshare/iMirror/Miracast

Office Software: WORD/EXCEL/PDF(Depends on APK install)

Vidoe /Pic Decoding:o  VP9-10 Profile-2 up to 4Kx2K@60fps

O  H.265 HEVC MP-10@L5.1 up to 4Kx2K@60fps

O  H.264 AVC HP@L5.1 up to 4Kx2K@30fps

O  H.264 MVC up to 1080P @60fps

O  MPEG-4 ASP@L5 up to 1080P@60fps (ISO-14496)

O  WMV/VC-1 SP/MP/AP up to 1080P@60fps

O  AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps

O  MPEG-2 MP/HL up to 1080P@60fps (ISO-13818)

O  MPEG-1 MP/HL up to 1080P@60fps (ISO-11172)

O  RealVideo 8/9/10 up to 1080P@60fps

O  WebM up to VGA

O  Multiple language and multiple format sub-title video support

O  MJPEG and JPEG unlimited pixel resolution decoding (ISO/IEC-10918)

O  Supports JPEG thumbnail, scaling, rotation and transition effects

O  Supports *.mkv,*.wmv,*.Mpg, *.Mpeg, *.Dat, *.Avi, *.Mov, *.Iso, *.MP4, *.Rm and *.Jpg file

Interface

AC:100-240V,50/60Hz;  DC:12V/3A

Max 32G

HDMI Input

USB 2.0

10/100M

Audio output, 3.5mm joint (can connect with earphone or speaker box)





Operation method of useage:
HDMI,USB Video,DisplayPort,MHL,Wireless





Package:

Product's Size(cm):   100*100*120mm

N.W(kg):  0.469kg
