| Type: | Axial Flow Fan |
|---|---|
| Certification: | CE,CSA,ROHS,UL, |
| Air Volume: | 117cfm |
| Voltage: | 12V |
| Brand Name: | X-FAN |
| Type: | DC FAN |
| Model Number: | RDH1225B1 |
| Place of Origin: | China (Mainland) |
| DC Axial Fan: | 12V |
| 120x120x25mm: | 0.30A |
| Ball bearing type: | 3000RPM |
| UL CUL TUV CE: | 70000hours |
Quick Details
Specifications
Spec:
DC Axial fan, 120x120x25mm,
12V, 3000rpm, 0.30A,
Ball bearing, 116.80CFM, 5.0mmH2O, 45dba
2 wires with auto restart
Features Optional:
24V, 48V are available;
Different speed such as medium speed, low speed are available for choose
Other models: RDM12225B1, RDL1225B1...
3 wires with tac output, or alarm detector
4 wires with tach output & PWM function all available
Life time:
Expectancy life time is about 70,000 hours while fan is operating at rated voltage in room temperature and 15%-65% RH enviroment.
Safety approvals:
with UL/CUL/TUV/CE certificates
Appliance:
Air cleaner, refrigeration, equipments etc.
DC Axial fan, 120x120x25mm,
12V, 3000rpm, 0.30A,
Ball bearing, 116.80CFM, 5.0mmH2O, 45dba
2 wires with auto restart
Features Optional:
24V, 48V are available;
Different speed such as medium speed, low speed are available for choose
Other models: RDM12225B1, RDL1225B1...
3 wires with tac output, or alarm detector
4 wires with tach output & PWM function all available
Life time:
Expectancy life time is about 70,000 hours while fan is operating at rated voltage in room temperature and 15%-65% RH enviroment.
Safety approvals:
with UL/CUL/TUV/CE certificates
Appliance:
Air cleaner, refrigeration, equipments etc.
