Clinical function

23 Reportable Parameters CBC

Testing speed

60 sampels/hour

Testing items

23 Reportable Parameters CBC:

Whole blood mode:

WBC,LYM#,NEU#,MON#,EOS#,BAS#,LYM%,NEU%,EOS%,BAS%,RBC,HGB,

MCH,MCHC,RBCMCV,HCT,MCV,MCH,MCHC,RDW-CV,RDW-SD,PLT,MPV,PDW,

PCT

4 Research parameters: ALY#,LIC#,ALY%,LIC%

3 HISTOGRAMS:WBC,RBC,PLT

3 Scattergrams for WBC DIFFERENTITAL and

1FOR BASOPHIL MEASUREMENT

Principle of operation

Trl-angle laser scatter,flow cytometry,chemical dye mehtod for 5

Part differential Analysis and WBC counting

Electrical impedance method for RBC and PLT counting

Non-cyanide method for hemoglobin testing

Communication

LAN port support HL7 protocol

Sample Volume

Whole blood mode 15l, capillary mode 15l,pre-diluted mode 20l

Operation screen

10.4 inch large TFT touch screen with user-friendly software

Data storage

up tp 50000 results,including numeric and graphical data

Printout

External laser printer.Inkjet printer,various printout formats and

Customized Formats

Data interface

4 USB ports, 1 LAN connection, support Bi-directional

 interface, can use the U disk for software updating LIS

Dimensions

360mm470mm430mm

Weight

28KG

Power Requirement

A.C100V-240V(50/60HZ),LESS THAN 250VA

Air pressure

70kpa-106kpa

Operating environment

Temperature:10%-30%, Humidity:20%-85%

Reagent

DIL-C Diluent,LYC-1 lyse,LYC-2 lyse,CLE-P Cleanser

Carryover

WBC 0.5%, RBC0.5%, HGB0.5%,PLT1.0%
