Specifications

1.Material: Gr1, Gr2, Gr3, Gr4, GR5.GR7...

2.Standard: GB/T3623-98, AMS, ASTM F136, ASTM F67, ASTM B863

3.Delivery: 5 to 15 days

4.Shipment: door to door by DHL, TNT, UPS, FEDEX / by air / by sea

5.Package: plywood case suitable for export and transport

6.FOB Port: Shanghai/tianjin, China

7.Annual Export Quantity: 1T/month

8.Characteristics: unique corrosion resistance, light weight, high strength, high performance.

9.Size:

Grade	Standard	Condition	Shape	size
Gr1,Gr2,Gr3,Gr4	ASTMF67	A hot rolled Forged Annealed (R/M/Y)	Round	Diameter (mm)	6.35~12.7 12.7~25.00 25.00~114.3	Length: According to your demand and max 9m
			Rectangular	Width (mm)	254
				Thickness (mm)	>4.75

Mechanical Requirements of gr2  titanium wire:



Grade	Tensile Strength, min		Yield Strength, 0.2 % Offset, min		Elongation Min,%	Reduction of Area, Min, %
	ksi	MPa	ksi	MPa
1 2 3 4	35 50 65 80	240 345 450 550	25 40 55 70	170 275 380 483	24 20 18 15	30 30 30 25

Dimension Tolerance of gr2 titanium wire



Diameter	0.1-0.3mm	0.3-0.8mm	0.8-2.0mm	2.0-6.0mm
Tolerance	+/- 0.025	+/-0.04	+/-0.05	+/-0.10
Length	200-500mm	500-1000mm	1000-2000mm	&2000mm
Tolerance	+/-1.0	+/-1.5	+/-2.0	+/-2.5

Quality Assurance

According to globally recognized standards, such as ASTM.

Chemical composition,Mechanical properties,Microstructure are strictly controlled

the Third Party Quality Test Certificate---Baoti Group

ISO Quality Management System

Cooperating with the most authoritative certification company in the world---BV Certification.
