| Brand Name: | FISolution |
|---|---|
| name: | Dust Cartridge Filter |
| Material: | Polyester |
| application: | Air Filtration |
| Type: | Dust |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Properties and features
1.Matching with filterbag tubeplate aperture
2.Imported polyester non-woven filter material, air flow, low resistance filtration efficiency.
3.PTFE film filter filtration efficiency of 99%
4.the filter cartridge installation is simple and convenient, reliable seal
5.According to the needs of customers,can choose a different form of installation, so that the replacement of the filter can be the most simple,the fastest.
Mainly apply to electric power, Metallurgy,chemical industry,machinery manufacturing industry's dust management.
Specification| Types | Filtration area | Temperature | Length | Weight | Air permeability | Material |
| Type 1 | 2.3m | 135 | 1m | 270g/m | 1.2m/m/min@12mmWC | Spun bond polyester |
| Type 2 | 4.6m | 135 | 2m | 270g/m | 1.2m/m/min@12mmWC | Spun bond polyester |
| Type 3 | 2.3m | 135 | 1m | 270g/m | 1.2m/m/min@12mmWC | Anti-static spun bond polyester |
| Type 4 | 4.6m | 135 | 2m | 270g/m | 1.2m/m/min@12mmWC | Anti-static spun bond polyester |
| Type 5 | 2.3m | 135 | 1m | 270g/m | 1.2m/m/min@12mmWC | Spun bond polyester+PTFE |
| Type 6 | 4.6m | 135 | 2m | 270g/m | 1.2m/m/min@12mmWC | Spun bond polyester+PTFE |
