| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Warranty: | one year guarantee |
| Brand Name: | SHANMU |
| Motor Type: | AC Motor |
| Condition: | New |
| Certification: | ISO9001 |
| Dimension(L*W*H): | 12500x2900x4100mm |
| Model Number: | PE600x900 |
| Place of Origin: | China (Mainland) |
| Capacity(t/h): | 70-130 |
| Power(W): | 120kw |
| Application: | primary crusher |
| Motor: | ZHONGTAI |
| Bearing: | ZWZ |
Quick Details
Specifications
IntroductionofMobile Jaw CrusherPlant
Mobile jaw Crusher Plant expands the concept field of coarse crushing and final crushing. Its design idea is based on the client's requirement, which clears faults of the crushing place, surroundings and the complex basic configurations. this series mobile jaw crusher really supply simpler, higher efficient lower cost for clients.
Model |
SMPE69 |
SMPE7510 |
SMPE9012 |
Transportation Length(mm) |
12000 |
13500 |
14600 |
Transportation Width(mm) |
2550 |
2550 |
2950 |
Transportation Height(mm) |
3750 |
4500 |
4500 |
Maximum Length(mm) |
12500 |
14000 |
14600 |
Maximum Width(mm) |
2900 |
2950 |
3300 |
Maximum Height(mm) |
4100 |
4900 |
5300 |
Tire Configuration |
Dualaxial |
Triaxial |
Triaxial |
Jaw Crusher |
PE600900 |
PE7501060 |
PE9001200 |
the Maximum Feeding Size(mm) |
500 |
630 |
750 |
Discharge Opening Size(mm) |
65-160 |
80-140 |
100-200 |
Capacity(t/h) |
70-120 |
110-250 |
220-320 |
