Quick Details

Brand Name: Dechuang
Accuracy: 1mm
Material: aluminum/PTFE/stainless steel
Measuring range: 150meter
display color: Blue/special custom
Model Number: DCRD1000B
Place of Origin: China (Mainland)
Application: especially be used in the high temperature & pressure, strong dust & multiple mixing environment, it can satisfy many applications for a large range measurement with high-precision requirements
Antenna type: PTFE/PEEK/PE, can choose Lens antenna guard/Anti-corrosive antenna/Antenna heat pipe/Quartz isolation flange;
Process temperature/humidity:: -60~20095%RH; -60~1000(with antenna heat pipe/quartz isolation flange)
Process connection: Flange, Thread
Brand name: Dechuang Electronic radar level meter pulse heavy dust level transmitter for lron ore fines
Housing material: Aluminium alloys single chamber or double chamber(220VAC Only with double chamber);

Specifications

1.Technical Parameters

Frequency range: 120GHz~130GHz, Frequency modulation sweep frequency width: 10GHz;

Measuring range: 0.1-50/100/150m;

Measurement resolution: 0.008m;

Accuracy: <1mm;

 Launch Angle: 1(with lens radome);

Dielectric constant range: 1.0100, Medium viscosity <1000cp;

Power supply: 9.0~42.0VDC(<5W) four wire or 110-250VAC, 50Hz/60Hz(<6W);

Signal output: 4~20mA (with HART/MODBUS/PROFIBUS*bus) or RS-485;

Site operation/: 2.6" inch Color screen / 4 key configurable;

Process temperature/humidity: -60~20095%RH; -60~1000(with antenna heat pipe/quartz isolation flange);

Housing material: Aluminium alloys single chamber or double chamber(220VAC Only with double chamber);

Antenna type:, PTFE/PEEK/PE, can choose Lens antenna guard/Anti-corrosive antenna/Antenna heat pipe/Quartz isolation flange;

Process pressure: -1~5MPa;  -1~32MPa(with quartz isolation flange);

: M20x1.5;

Recommend the cables: AWG18 or 0.75mm;

Protection grade: IP67;

: ExiaCT6Ga, ExdiaCT6Gb;

Installation type: M56x2 screw thread or DN50 flange;

2.Main Features

1. Not be affected by atmospheric precipitation;

2. the ambient temperature is -60C;

3. Being Installed on the outside of tank;

4. the antenna inside of the level transmitter is protected by fluoroplastic lens heating;

5. the measuring radiation is narrow, easy to install and measurement sensibility;

6. the accuracy of the level measurement can't be limited by the temperature of tank;

7. Evaporation and dust will not affect the measurement;

8. Boiling liquid level measurement;

9. Corrosive liquid level measurement, non-contact, non-corrosion, stable measurement;


3.Application

Measurable products:Petroleum, petroleum products, heavy oil, asphalt, gasoline and other light-colored petroleum products, acid, food, beer, alcohol, milk, liquefied gas, sewage, solution, phenol, ore, cement, seeds, coal ash, solvent, crushed stone, mineral fertilizer, dye, chemical reactor with "agitator", eucalyptus oil, coal tar, slag, syrup, etc.
