| Model No. |
| ZDNY-320C72 |
ZDNY-325C72 |
ZDNY-330C72 |
ZDNY-335C72 |
ZDNY-340C72 |
|
|---|
| Warranty |
|
|---|
| Product Warranty |
12 Years |
|---|
| Power Warranty |
12 Years of 90% Output Power, 25 Years of 80.2% Output Power |
|---|
| Electrical Data at STC |
|
|---|
| Maximum Power (Pmax) |
| 320 Wp |
325 Wp |
330 Wp |
335 Wp |
340 Wp |
|
|---|
| Voltage at Maximum Power (Vmpp) |
| 37.15 V |
37.46 V |
37.65 V |
37.88 V |
38.02 V |
|
|---|
| Current at Maximum Power (Impp) |
| 8.62 A |
8.68 A |
8.77 A |
8.85 A |
8.95 A |
|
|---|
| Open Circuit Voltage (Voc) |
| 45.96 V |
46.25 V |
46.45 V |
46.67 V |
46.79 V |
|
|---|
| Short Circuit Current (Isc) |
| 9.1 A |
9.16 A |
9.23 A |
9.29 A |
9.37 A |
|
|---|
| Panel Efficiency |
| 16.49 % |
16.75 % |
17.01 % |
17.26 % |
17.52 % |
|
|---|
| Power Tolerance (Positive) |
| + 3 % |
+ 3 % |
+ 3 % |
+ 3 % |
+ 3 % |
|
|---|
| |
Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25C |
|---|
| Electrical Data at NOCT |
|
|---|
| Temperature |
| 472 C |
472 C |
472 C |
472 C |
472 C |
|
|---|
| |
Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20C |
|---|
| Thermal Ratings |
|
|---|
| Operating Temperature Range |
-40~85 C |
|---|
| Temperature Coefficient of Pmax |
-0.4 %/C |
|---|
| Temperature Coefficient of Voc |
-0.303 %/C |
|---|
| Temperature Coefficient of Isc |
0.053 %/C |
|---|
| Maximum Ratings |
|
|---|
| Maximum System Voltage |
1000 V |
|---|
| Series Fuse Rating |
15 A |
|---|
| Material Data |
|
|---|
| Panel Dimension (H/W/D) |
1956x992x45 mm |
|---|
| Weight |
23 kg |
|---|
| Cell Type |
Monocrystalline |
|---|
| Cell Size |
156156 mm |
|---|
| Cell Number |
72 |
|---|
| Junction Box Diodes |
3 |
|---|
| Cable Crossection |
4 mm2 |
|---|
| Cable Length |
900 mm |
|---|
