| Brand Name: | CHIKEK |
|---|---|
| Card type: | MIFARE DESFire,MIFARE Classic,CPU card, I CODE SLI |
| Communication: | UART TTL |
| Dimension: | 34.5mmx58mmx4mm |
| Frequency: | 13.56MHz |
| Model Number: | CHK361MT |
| Place of Origin: | China (Mainland) |
| Antenna: | Internal |
| Supported Standard: | ISO14443A/B,ISO15693,ISO7816 |
Quick Details
Specifications
Key Features:
- 3.3V ~ 5V DC Power supply, UART TTL communication port;
- Compatible with ISO14443 A/B, ISO15693 standard;
- R/W MIFARE Classic 1K /4K, MIFARE Ultralight/Ultralight C, MIFARE DESFire, ISO14443A-4 contactless CPU card, I CODE SLI, etc;
- Support DES/3DES/AES/MAC encryption algorithm;
- Available to operate MIFARE DESFire PICC level, Application ID create /delete /format, etc, Support Application/File create, delete, format, etc;
- Internal with 1 PSAM socket, ISO7816 T=1 PSAM card standard;
- Internal antenna, reading range up to 5~7 cm
Technical Parameters:
Electrical Specification |
|
Power supply |
DC 3.3V ~ 5V |
Power consumption |
<150mA |
Operation frequency |
13.56MHz |
Baudrate |
9600~115200 bit/s ( default115200bps) |
Interface |
UART TTL |
Antenna |
Internal |
Reading range |
50-70mm (depends on tag and antenna size) |
Mechanical Specifications |
|
Dimension |
34.5mmx58mmx4Mm (LxWxH) |
Weight |
10g |
Material |
FR-4, Blue |
Model |
CHK361MT |
Environmental Conditions |
|
Operation temperature |
-20C+80C |
Storage temperature |
-40C+85C |
Humidity |
Relative humidity 5%95% |
Supported Standard/ Tags |
|
ISO14443 A |
Read/write: MIFARE Classic 1K /4K, MIFARE Ultralight, MIFARE Ultralight C, MIFARE DESFireEV1, MIFARE Smart MX, MIFARE Plus S / X, MIFARE Pro X, NTAG 21x
Read UID only: Read UID only of all other ISO14443A RFID tags |
ISO14443 B |
SRI4K, SRIX4K, AT88RF020, 66CL160S, SR176 |
ISO15693 |
EM4135, EM4043, EM4x33, EM4x35, I-Code SLI / SLIX, M24LR16/64, TI Tag-it HF-I, SRF55Vxx (my-d vicinity) |
ISO7816 |
PSAM T=0, T=1 standard |
SDK information |
|
Demo software |
Windows, C# program language |
Files |
Comprotocol document API document User Manual Demo.Exe |
Note: Other functions and details to be continued and upgraded
