| Output: | Analog Sensor |
|---|---|
| Theory: | Resistance Sensor |
| Usage: | Pressure Sensor |
| Brand Name: | santwell |
| material: | alloy steel |
| Model Number: | DS-1AX |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
1.Appliation
Can be used for the storage measurement.
2.
| Technical Parameter | |
| Rated Load | 15t,20t |
| Sensitivity | 2.0000m±0.002mV/V |
| Total Error | ±0.02%F.S |
| Creep(30minutes) | ±0.02%F.S |
| Recommended Excitation Voltage | 5V~18V(AC or DC) |
| Maximum Excitation Voltage | 24V(AC or DC) |
| Zero Balance | ±1%F.S |
| Input Impedance | 380±10Ω |
| Output Impedance | 350±5Ω |
| Insulation Impedance | ≥5000MΩ |
| Safe Overload | 150%F.S |
| Ultimate Overload | 200%F.S |
| Operating Temperature Range | (-30~+70)℃ |
| Compensated Temperature Range | (-20~+60)℃ |
| Temperature Effect on Load | ±0.02%F.S/10℃ |
| Temperature Effect on Zero | ±0.02%F.S/10℃ |
| Construction | Alloy Steel |
| Protection Class | IP67&IP68 |
| Citation | GB/T7551-2008/OIML R60 |
| Mode of Connection | Input+E:Red Input-:EBlack Output+S:Green Output-S:White |
