| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Weight: | 500kg |
| Power(W): | 1900 |
| Brand Name: | FiVE |
| Condition: | New |
| Warranty: | 1Year |
| Certification: | CE |
| Dimension(L*W*H): | 2100*850*1200mm |
| Voltage: | Custimized |
| Model Number: | QTJ500 |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Features:
Cutting width is adjusted by changing blade carrier or blade sleeve.
Floating unloading system to prevent meat from sticking on blade.
Conveying speed can reach to 18m/min, high production capacity guaranteed.
High cutting precision, minimum width about 5mm.
High efficiency guaranteed by multi blade Cutting.
Capable of different thickness cutting combined in single cutting.
Detachable blade carrier, input belt and output belt, easy to clean.
Mist spraying design smoothing the cut.
Adopt imported module belt with long life.
Adopt SIMEMENS part with safety service, CE approved.
Adopt SUS304 and engineering plastic, easy to clean meet HACCP.
Easy operation and lower maintenance.
Benefits:
Precise cutting width.
Minimize labor, high efficiency.
Two equipment get together to produce same size strip.
Work with smart cutter produce many other products.
Model |
QTJ300 |
QTJ500 |
Belt Width |
300mm |
500mm |
Belt Speed |
3-18m/min Adjustable |
3-18m/min Adjustable |
Cutting Thickness |
5-45mm(70mm customized) |
5-45mm(70mm customized) |
Cutting Capacity |
200-500kg/h |
500-1000kg/h |
Raw Material Width |
300mm |
500mm |
Height(input/output) |
1050±50mm |
1050±50mm |
Power |
1.5KW |
1.9KW |
Dimension |
1500*640*1000mm |
2010*903*1615mm |
