Specifications |
HDD total weight |
25. |
System voltage |
24V |
HDD Working overall size (MM) |
921725602804 |
HDD Walking overall size (MM) (MM) |
930025602600 |
Diesel specification |
Diesel engine |
Cummins 6LTAA8.9-325 |
Engine Type |
Turbo-charging, 4 strokes, 6 cylinders water cooling |
Engine Rate Power |
239kW/2200 |
Total displacement |
8.9L |
Emission standard |
uro2 |
Operating performance |
Pullback Capacity(max) |
800kN |
Thrust Capacity(max) |
800kN |
Spindle Torque(max) |
25000 N.. |
Spindle Speed |
0-80 rp |
Ground Drive Speed |
1.6 / |
Max pullback speed (m/min) |
15 |
Incidence Angle |
10°-22° |
Grade ability |
25° |
Incidence angle |
20° |
Departure angle |
14° |
Elevating capacity |
3000kg |
Drilling tools |
Drill diameter |
Φ175mm |
Length of Rod |
6m |
Diameter of Rod |
Φ102mm |
Diameter of Reamer |
Φ400-Φ1200 |
Tank Capacity |
Fuel Tank Capacity |
270L |
Hydraulic oil Tank Capacity |
250L |
Mud Pump |
|
Max Pressure of Mud Pump |
10 Mpa |
Max Flow Rate of Mud Pump |
500L/min |
Mud Mixed Station |
|
Type of Mud Mixed Station |
Split type |
Mud Pump Capacity |
5m3 |
