| Rated capacity (kg) |
700 |
| Tipping load(kg) |
1400 |
| Bucket capacity (cbm) |
0.4 |
| Lifting force (kg) |
1950 |
| Hydraulic pump flow (L/min) |
75 |
| Engine power (HP) |
50 |
| Weight(kg) |
3100 |
| Max traveling speed (km/h) |
12 |
| Grade ability (degrees) |
20 |
| Tire |
10-16.5 |
| Fuel/hydraulic oil tank (L) |
60/60 |
| A.Height at maximum extension |
3670mm |
| B.Hinge pin height |
2900mm |
| C. Total height |
2050mm |
| D. Length with bucket |
3420mm |
| E. Length without bucket |
2640mm |
| F. Width with bucket |
1740mm |
| G. Track width |
1450mm |
| H. Wheel base |
991mm |
| J.Ground clearance |
185mm |
| K. Dumping angle |
40 degree |
| L.Dumping height |
2230mm |
| M.Maximum Reach |
710 |
