| Brand Name: | Lefilter |
|---|---|
| Medium Material: | Fiberglass |
| Filtration Grade: | Ulpa Filter |
| Construction: | Cartridge Filter |
| Condition: | New |
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Warranty: | not available |
| Certification: | ISO9001 |
| Weight: | 3kg |
Quick Details
Specifications
CONSTRUCTION
Media Polyester or Polypropylene
Gaskets/End Cap Integral thermally bonded polyester or polypropylene. Optional buna-n or viton with metal end caps.
Core None in standard construction. If required louvered, carbon steel.
OPERATIONAL DATA
Recommended Element Change Out: 12 - 14 PSID /.83 -.97 bar.
See chart below for collapse strengths
Maximum Operating Temp: Polyester 240 F / 116 C Polypropylene 180 F / 82 C Note: Temps from 200 - 240F require a core for 4.5" & 5.5" O.D. Filters.
Micron Ratings: 0.5, 1, 5, 10 SCW=0.3
Recommended Torque to Seal Filters: 5-10 ft-lbs NOTE: this Torque should not be exceeded.
