| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Warranty: | 1 year |
| Certification: | CE ISO |
| Brand Name: | wodetec |
| Condition: | New |
| Weight: | 610kg |
| Dimension(L*W*H): | 1900x850x1250mm |
| Voltage: | 220V,380V, 440V,660V |
| Model Number: | WDS1500G |
| Place of Origin: | China (Mainland) |
| Hose Inner Diameter: | 38mm |
| Max Aggregate Size: | 8mm |
| Keywords: | wet shotcrete pump |
| Pressure: | 1.5 Mpa |
| Color: | Color |
| Output: | 1.5-3m3/h |
| Max. Aggregate: | 8mm |
| The Squeeze Hose: | ID 50mm |
| Conveying Hose: | ID 38mm |
| hopper volume: | 200 Liter |
| Oil tank: | 120 Liter |
Quick Details
Specifications
Feature:
1) Highly reliable direct drive planetary gearbox
2) Infinite speed variation
3) Easily operating on site work
4) Standard spare part supply
Item |
Description |
Pressure |
1.5 Mpa |
Output |
1.5-3m3/h |
Max. Aggregate |
8mm |
the Squeeze Hose |
ID 50mm |
Conveying Hose |
ID 38mm |
Squeeze pump |
LH50-455 |
Power |
Honda GX390 Gasoline engine |
Overall Dimension |
1900x850x1250mm |
Hopper volume: |
200 Liter |
Oil tank |
120 Liter |
Weight |
610kg |
Requested air compressor |
3m3/min, 0.5Mpa Pressure |
No. |
Description |
Qty. |
Unit |
1 |
WDS1500G main machine |
1 |
set |
2 |
Pump squeeze tube |
1 |
pcs |
3 |
Conveying hose, ID38, L10m |
2 |
pcs |
4 |
Reducer 2'/1.5' |
1 |
pcs |
5 |
Shotcrete nozzle assy. |
1 |
set |
6 |
Nozzle tip |
1 |
pcs |
7 |
Air filter |
1 |
pcs |
8 |
Oil level gauge |
1 |
pcs |
9 |
clamp |
1 |
pcs |
10 |
Clean ball |
2 |
pcs |
11 |
Accessories |
1 |
Set |
1.We are China Leading of shotcrete pump.
2.Alibaba Assessed 1 years Gold Supplier.
3.100% QC inspection Before Shipping.
4.Best Quality & Best Service with Competitive price.
