Powerful engine
Low center of gravity, small turning radius, more stable and reliable
Comfortable seat for long-time operation
Safe overhead guard
Rear light for working in the dark
Dual air filter
Streamline balance weight
Side shifter is optional
Optional mast: 2-stage 3.3m/3.5m/4mmast; 3-stage4.5m/5m/5.5m/6m/7.3mmast.
Optional engine: EURO II/III China engine; DEUTZ-DACHAI engine; ISUZU engine;YANMAR engine.
| 1 |
Model |
SSL30DF |
SSL35DF |
|---|
| 2 |
Rated capacity |
3000kg |
3500kg |
| 3 |
Engine model |
490BPG |
490BPG |
| 4 |
Power |
39kw |
39kw |
| 5 |
Rated speed |
2650rpm |
2650rpm |
| 6 |
Displacement |
2.67L |
2.67L |
| 7 |
No. of cylinder |
4 |
4 |
| 8 |
Load center |
500mm |
500mm |
| 9 |
Power type |
Diesel |
Diesel |
| 10 |
Transmission |
Hydraulic |
Hydraulic |
| 11 |
Lifting height |
3000mm |
3000mm |
| 12 |
Free lifting height |
80mm |
80mm |
| 13 |
Turning radius |
2500mm |
2500mm |
| 14 |
Overall length |
3800mm |
3800mm |
| 15 |
Overall width |
1230mm |
1230mm |
| 16 |
Overall height (mast lowered) |
2095mm |
2110mm |
| 17 |
Overall height (mast raised) |
4080mm |
4270mm |
| 18 |
Overall height (overhead guard) |
2110mm |
2110mm |
| 19 |
Fork length |
1220mm |
1220mm |
| 20 |
Fork width |
125mm |
125mm |
| 21 |
Fork thickness |
45mm |
50mm |
| 22 |
Max. Driving speed (with/without load) |
18/20 km/h |
17/19km/h |
| 23 |
Max. Lifting speed (with load) |
400mm/s |
375mm/s |
| 24 |
Max. Traction (with/without load) |
15.5/10.5 kn |
16/11 kn |
| 25 |
Gradeability (with/without load) |
15/20 % |
15/20 % |
| 26 |
Tilting angles(forward/backward) |
6/12 degree |
6/12 degree |
| 27 |
Service weight |
4320kg |
4580kg |
| 28 |
Front overhang |
465mm |
465mm |
| 29 |
Wheel base |
1700mm |
1700mm |
| 30 |
Front tread |
1000mm |
1000mm |
| 31 |
Rear tread |
970mm |
970mm |
| 32 |
Front tire |
289-15 |
289-15 |
| 33 |
Rear tire |
6.50-10 |
6.50-10 |
