| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Power(W): | 220W |
| Brand Name: | Qingdao Leader Machinery co.,ltd. |
| Application: | Sheet |
| Condition: | New |
| Certification: | ISO CE ISO 9001-2008 |
| Place of Origin: | China (Mainland) |
| Automatic Grade: | Automatic |
| Screw Design: | Single-screw |
| Screw No.: | Single-screw |
| Sheet Width: | 700-2200mm |
| Sheet Thickness: | 0.5-30mm |
| Extruder Model: | Single Screw Extruder 90/33, 120/33 |
| Three Roller Calendar: | Alloy Steel Material, Chromed on Surface |
| Sheet Applications: | Packing, Stationery, Chemicals, Construction etc |
Quick Details
Specifications
1.Brief Introduction:
1. Usual sheet width:
700, 900, 1020, 1200, 1300, 1400, 1500, 1700, 1800, 2100, 2200mm
2. Usual sheet thickness:
0.5-2mm, 1.5-10mm, 6-20mm, 3-30mm
3. High Efficiency Single Screw Extruder:
Special screw structure, imported world-known thermocontrollers, electronics, hard gear face reducers to ensure high effective material extrusion capacity.
4. T -type die head:
Die head material: special mould steel 5CrNiMo,
Suitable compression ratio to ensure uniform flow stability.
5. Three-roller calendar::
Calendars material: alloy steel, chromed on the surafce.
According to the material properties, adopting vertical three-roller, oblique three-roller, horizontal three-roller calendar. Internal roller temperature control using a unique flow channel, so that the stability of uniform distribution roller. the independent oil temperature control for three roller to ensure more stable and exact control.
6. Cooling frame:
According to product specifications, configurations with different specifications of the stainless steel cooling roller
7. Edge cutting devices:Trimming can be divided into manual and automatic, three-dimensional configuration tool adjustment device, width adjustable.
8. Cut off machine: Saw cutting or knife cutting, thin type and non-friable type sheet generally usually knife cut, adopted high-quality alloy cutting tools, sharp and durable
9.Twin position coiler:
Torque motor control with length preseting devices
2.Techincal parameters:
| PAR T1 this LINE CONSISTS of (COMPULSORY) | ||
| Automatic vacuum feeding machine | 1 set | |
| High efficiency single screw extruder (65/33, 75/33,90/33,120/33) | 1 set | |
| Hydraulic exchanging unit | 1 set | |
| T-type /hanger type die head (JC-Times brand) | 1 set | |
| Three Roller Calendars (alloy steel material ) | 1 set | |
| Rollers thermoforming machine | 1 set | |
| Cooling frame and edge cutting unit | 1 set | |
| Haul off machine | 1 set | |
| Plastic cutting machine-guillotine | 1 set | |
| Twin position sheet winder | 1 set | |
| Stacker | 1 set | |
| Electrical cabinet (ABB,Omron, RKC,Schneider, Siemens etc) | ||
| Spare parts | 1 set | |
| PART 2 ACCESSORY MACHINE PARTS (OPTIONAL) | ||
| Air compressor | 1 set | |
| Industrial water chiller | 1 set | |
PART how to buy our machines? Operation Guide as Follows:
1. Please kindly inform me specification of the products you want to produce:
(1) If you want plastic pipe, plz Inform us pipe diameter & thickness (SDR)
(2) If you want plastic sheet, plz inform us sheet width & thickness&applications
(3) If you want plastic profile, plz send us general size, picture or drawings.
2. We will send you the quotation details according to your requirements.
3. Discuss each item of the quotation and get the agreement.
4. Sign the P/I and Contract and send us 40% prepayment and we will begin to arrange production.
5. When the machine is ready, customers come to our factory to testing machine.
6. Send us the 60% balanced payment and we will arrange delivery.
PART Quality Guarantee and after Sale Service
1. Warranty for machinery: 18months for mechanical parts, 12 months for electrical parts.
during the guranteed time, damages because of machine itself,we will change new ones for you free.
Damaged made by human, we will also change new one for you based your extra cost.
2. Technical service and support will be forever.
3. Installtion and commissioning
the seller will dispatch four 1-2 engineers from the seller to the buyer's factory for installation and commissioning and training till the buyer's workers can operate the machines independently.
