Quick Details

Brand Name: HarshMet
Material: Silicone Rubber
Sealing Class: IP68
Color: Black
Application: RF Connector
Model Number: CST Series
Place of Origin: China (Mainland)

Specifications

CST-M series weatherproofing solution is a cold shrink tube with built-in mastic. It is a one-step, time-saving and reliable weatherproofing design. The innovatively unique design economically protects RF coax connections at wireless cell sites and CCTV networks against water, dust, and other environment corrosion in a quick, reliable and safe way.

Application
the main application is the sealing of coax connectors used in the wireless communication antenna market. these mainly outside installed connectors require an extra sealing.

Features

  • Sealing Class: IP68
  • Operating Temperature :-60 C~+200 C
  • Shrink ratio: 2.5:1 ~ 4:1
  • Colors:Black or Grey
  • UV and Ozone resistant
  • Superior tear resistant
  • Acid and alkalis resistant

Selection Chart

P/N CST-M12ARD CST-M1278S
(Short Version)		 CST-M-1278 CST-M12ARN
Connector Type 7/16 DIN, N Type and Min DIN Type 7/16 DIN, N Type and Min DIN Type 7/16 DIN, N Type and Min DIN Type N Type and Mini DIN Type
RF Connections 1/2" & 1/2" Superflex Jumper to Antenna, RRU, TMA Devices etc 1/2" & 1/2" Jumper to 7/8" & 7/8" Superflex Feeder Connections, 1/2" to 1/2" Splice, 1/2" to 5/8" Splice, 5/8" to 5/8" Splice 1/2" & 1/2" Jumper to 7/8" & 7/8" Superflex Feeder Connections, 1/2" to 1/2" Splice, 1/2" to 5/8" Splice, 5/8" to 5/8" Splice 1/2" & 1/2" Superflex Jumper to Antenna, RRU, TMA Devices etc
Diameter Range 13-40mm 13-40mm 13-40mm 9-24mm
Length 140mm 200mm 280mm 110mm

Other specification and applications are available on your specific request, please contact us.
 Silicone Cold Shrink Tube with Mastics
