Quick Details

Brand Name: Eagleflying
Compressive strength: 0.8-3.5Mpa
Color: According to your requirement
Keywords: Steel wire mesh skeleton plastic (PE) composite pipe
Grade: CJ/T189-2007
Place of Origin: China (Mainland)

Specifications

Steel wire mesh skeleton plastic PE composite pipe
Pressure Pipeline Series/Steel wire mesh skeleton plastic composite pipe

1. Steel wire mesh skeleton plastic (PE) composite pipe

Executive standard:CJ/T189-2007 Technical specifications ofSteel wire mesh skeleton plastic (PE) composite pipe

Steel wire mesh skeleton plastic (PE) composite pipe (referred to as composite pipe) is reinforced by a high-strength steel wire mesh framework spirally formed from left and right sides. High density polyethylene (HDPE) was used as the matrix, and the steel wire mesh framework was closely connected with the inner and outer layers of high density polyethylene (HDPE) with a high performance adhesive resin layer. the bonding resin is a kind of high performance bonding material. It belongs to HDPE modified material. It can melt into HDPE under heating condition. At the same time, its polar bond has strong bonding performance with steel wire. Because of the use of adhesive resin, the problem of no connection factor between steel and polyethylene has been successfully solved, and the composite effect is better.

Product features:

It has the characteristics of strength, rigidity and impact resistance, similar to the low linear expansion coefficient and creep resistance of steel pipe.

Double-sided anti-corrosion, with the same anti-corrosion performance as plastic pipes, high temperature and corrosion resistance, low thermal conductivity.

with excellent structure, the reinforced skeleton of the pipe and the inner and outer plastics are mutually inclusive and become a whole without the worry of peeling the inner and outer plastics and the reinforcement.

the composite of steel and plastic materials is uniform and reliable, which overcomes the rapid cracking of PE pipes. Because the steel and plastic materials are structural composite forms, the phenomenon of rapid stress cracking that plastic pipes are difficult to overcome will not occur.

the inner wall is smooth, scale-free, flow resistance is small, and the head loss of the pipeline is 30% lower than that of the steel tube.

Pipes of different pressure grades can be produced by adjusting the diameter of steel wire and the number of steel wires.

Light weight, easy installation, pipeline connection using electric fusion joint, strong axial tension resistance, mature and reliable connection technology, complete development of pipe specifications, can be connected with other pipelines, valves, equipment.

the overall reliability of the pipes is high. under normal use, the service life can reach 50 years, the comprehensive price ratio is excellent, and it is sanitary and non-toxic. It is an ideal substitute for steel pipes, spheroidal graphite pipes and pure plastic pipes.

Correction coefficient of temperature and pressure

Temperature t/℃
0≤t≤20
20t≤30
30t≤40
Correction factor
1
0.95
0.90

Main technical performance

No.
Technical performance item
Index
1
Medium temperature
-20℃≤t≤65℃
2
Modulus of elasticity
2.8-3.0GPa
3
Corrosion resistance
Good
4
Thermal conductivity
0.15-0.2w/m.K
5
Wall roughness
Ra.0.007
6
Coefficient of linear expansion
12-1510-5m/m.K

Physical and mechanical properties

Usage symbol
Test temperature (℃)
Short-term hydrostatic pressure and blasting pressure/Mpa
Time/h
Performance requirement
LF
20℃
Nominal pressure2
1
No rupture, No leakage
20℃
Blasting pressure≥Nominal pressure3
Blasting
Q
20℃
Nominal pressure1.62
1
No rupture, No leakage
20℃
Blasting pressure≥Nominal pressure3.31.6
Blasting
Thermal stability (200℃)
>20min
Note: Blasting pressure test is not mandatory when DN≥ 250

Product specification

Nominal diameter mm
Average outside diameter
Min. Thickness of polyethylene outer layer
Min. Nominal diameter of steel wire
Nominal pressure MPa
0.8
1.0
1.5
2.0
2.5
3.5
mm
mm
mm
mm
Any point of wall thickness e Range of values/mm
>
<
>
<
>
<
>
<
>
<
>
<
50
50
51.2
1.5
0.5
-
-
-
-
5.0
6.2
5.5
6.7
6.0
7.5
6.5
8.0
63
63
64
1.5
0.5
-
-
-
-
5.5
6.7
6.0
7.2
6.5
8.0
7.0
8.5
75
75
76.2
1.5
0.5
-
-
-
-
6.0
7.2
6.5
7.7
7.0
8.5
7.5
9.0
90
90
91.4
2.0
0.5
-
-
-
-
6.5
8.0
7.0
8.5
7.5
9.0
8.0
9.5
110
110
111.5
2.0
0.5
-
-
6.0
7.5
7.0
8.5
7.5
9.0
8.0
9.5
8.5
10.0
125
125
126.6
2.0
0.6
-
-
6.0
7.5
7.5
9.0
8.0
9.5
8.5
10.0
9.5
11.0
140
140
141.7
2.0
0.6
-
-
6.0
7.5
8.0
9.5
8.5
10
9.5
11.0
10.5
12.0
160
160
162
2.5
0.6
-
-
6.5
8.0
9.0
10.5
9.5
11.0
10.5
12.5
11.5
13.5
200
200
202.3
2.5
0.6
-
-
7.0
8.5
9.5
11.0
10.5
12.5
12.5
14.5
13.0
15.2
225
225
227.5
2.5
0.6
-
-
8.0
9.5
10.0
12.0
10.5
12.5
12.5
14.5
-
-
250
250
252.5
2.5
0.6
8.0
9.5
10.5
12.5
12.0
14.2
12.0
14.2
14.2
15.2
-
-
315
315
317.7
3.5
0.6
9.5
11.0
12.0
14.0
13.0
15.5
13.0
15.5
15.5
17.0
-
-
355
355
357.8
3.5
0.8
10.0
11.8
12.5
14.7
14.0
16.5
-
-
-
-
-
-
400
400
403
3.5
0.8
10.5
12.5
13.0
15.2
15.0
17.8
-
-
-
-
-
-
450
450
453.2
3.5
0.8
11.5
13.5
14.0
16.5
16.0
18.8
-
-
-
-
-
-
500
500
503.2
3.5
0.8
12.5
14.7
16.0
18.8
18.0
20.8
-
-
-
-
-
-
560
560
563.2
3.5
0.8
17.0
20.0
20.0
23.0
21.0
24.0
-
-
-
-
-
-
630
630
633.2
3.5
0.8
20.0
23.0
22.0
25.0
24.0
27.0
-
-
-
-
-
-
710
710
713.8
3.5
1.0
23.0
26.0
26.0
29.5
-
-
-
-
-
-
-
-
800
800
803.8
3.5
1.0
27.0
30.5
30.5
33.5
-
-
-
-
-
-
-
-

Physical properties

Test requirement of short-term hydrostatic pressure and blasting pressure
Usage symbol
Test temperature (℃)
Short-term hydrostatic pressure and blasting pressure/Mpa
Time/h
Performance requirement
L, T
20℃
Nominal pressure2
1
No rupture, No leakage
20℃
Blasting pressure≥Nominal pressure3
Blasting
Q
20℃
Nominal pressure1.62
1
No rupture, No leakage
80℃
Nominal pressure1.620.6
165
No rupture, No leakage
20℃
Blasting pressure≥Nominal pressure3.31.6
1
Blasting
Note: Blasting pressure test is not mandatory when DN≥ 250

Correction coefficient of temperature and pressure

Temperature t/℃
0≤t≤20
30≤t≤40
40≤t≤50
50t≤60
Correction factor
1.0
0.90
0.86
0.81

Peel strength


the peeling strength should be greater than or equal to 100N/cm according to the Hu test method specified in GB/T 2791.



2. Fittings

Electrofusion (electric melting) sleeve connection

Pressure grade: 0.8MPa1.6MPa

Specification type: dn50mmdn1000mm

Nominal pressure: the nominal pressure corresponding to the electric melting sleeve connection shall meet the requirements of the table below.

Electrofusion (electric melting) flange connection

Pressure grade: 0.8MPa1.6MPa

Specification type: dn50mmdn800mm

Nominal pressure: the nominal pressure corresponding to the electric melting flange connection shall meet the requirements of the table below.

Nominal pressure corresponding to the electrofusion (electric melting) sleeve connection

Nominal pressure corresponding to the electrofusion (electric melting) sleeve connection
Specification of pipe fittings (dn/mm)
Nominal pressure (MPa)

Specification of pipe fittings (dn/mm)
Nominal pressure (MPa)
0.8
1
1.25
1.6

0.8
1
1.25
1.6
50

50
63

63
75

75
90

90
110

110
125

125
140

140
160

160
200

200
225

225
250

250
315

315
355
/

355
/
400
/

400
/
450
/

450
/
500
/
/

500
/
/
560
/
/

560
/
/
630
/
/

630
/
/
710
/
/
/

710
/
/
/
800
/
/
/

800
/
/
/

Electrofusion (Electric melting) sleeve table:

Note:Means applicable and / means not applicable.Remark:the Max. Pressure can not exceed 1.6MPa, can not be directly constructed in the underground, can be used buried.

Electrofusion (Electric melting) flange table:

Note:Means applicable and / means not applicable.Remark:the Max. Pressure can not exceed 1.6MPa, can not be directly constructed in the underground, can not be used for burial, can be used for water supply and drainage, air pressure and gas drainage.
