Waterproof Vibration Transmitter YKF-YB40
YKF-YB40 vibration transmitter combined vibration sensor and transmission module together.It is for real-time monitoring of vibration of rotating mechanical bearings, also known as integrated vibration sensor. It integrates the vibration sensor and the signal conditioning circuit. It can directly convert the collected vibration signal into a 4~20mA current signal or the RS485 digital output, then transmit to control system.
It is widely used in bearing vibration measurement and real-time monitoring of rotary machinery such as submersible pumps, outside or high humidity equipment, like fans, etc.
Technical Specs:
Input: +DC24V
Measuring range: 010/20*/50/100mm/s or 0100/200*/500um
Output: 4-20mA (or 1-5V/1-10V or RS485)
Output Impedance: <500Ω
Frequency Response: 10Hz1000Hz
Max acceleration: 10g
Accuracy: <F.S±3%
Measurement Direction: vertical or horizontal
Working temperature: -40℃85℃
Mounting thread: M101.510mm
Shell material: 304 stainless steel
Size/Weight: φ3373mm, about 350g
Output way: two-wire or three-wire
Available cable: 2m, 5m, 8m
