| Rated Voltage: | 250~500v |
|---|---|
| Capacitance: | 1~80uf |
| Application: | AC / Motor |
| Type: | Polypropylene Film Capacitor |
| Brand Name: | MD |
| Operating Temperature: | -40~85 |
| Package Type: | Surface Mount |
| Model Number: | CBB60 |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Product parameters and certification:
SAfety approvals: |
CQC/UL/VDE |
ApProval standard |
GB/T3667,UL810,EN60252 |
Climatic category |
25/70/21,25/85/21,40/70/21,40/85/21 |
Rated voltage |
150VAC~600VAC(50-60Hz) |
Capacitance range |
1uf~80uf |
Capacitance tolerance |
+_5%(J),+_10%(K),+10%(U),-5%(U) |
Testing voltage | |
BEtween terminals |
2*Un(VAC)/5s |
BEtween terminals and case |
2*Un+1000(VAC)/5S(>=2000VAC) |
Insulation Resistance(20℃) | |
between terminals |
>=2000MΩ,UF(500VDC,5s) |
Tangent of loss angle(20℃) |
<=0.002(100Hz) |
Class of safety protection |
S0/S3 |
FaulT Currency |
10,000AFC(UL810) |
Capacity and sizing
Capacitor(uf) |
250/300VAC |
300VAC |
400-450VAC |
500VAC | ||||
D |
H |
D |
H |
D |
H |
D |
H | |
6uf |
30 |
50 |
/ |
/ |
30 |
60 |
/ |
/ |
8uf |
30 |
60 |
/ |
/ |
35 |
60 |
/ |
/ |
10uf |
30 |
60 |
/ |
/ |
40 |
60 |
40 |
70 |
12uf |
30 |
60 |
35 |
60 |
40 |
60 |
/ |
/ |
15uf |
35 |
60 |
/ |
/ |
40 |
70 |
/ |
/ |
18uf |
35 |
60 |
/ |
/ |
45 |
70 |
/ |
/ |
20uf |
40 |
60 |
40 |
70 |
45 |
70 |
45 |
80 |
25uf |
40 |
60 |
45 |
70 |
45 |
80 |
/ |
/ |
30uf |
40 |
70 |
45 |
80 |
45 |
90 |
50 |
90 |
35uf |
/ |
/ |
/ |
/ |
50 |
90 |
/ |
/ |
40uf |
45 |
70 |
45 |
90 |
50 |
100 |
55 |
110 |
