| Rated Voltage: | 250~500v |
|---|---|
| Capacitance: | 3~100uf |
| Application: | AC / Motor |
| Type: | Polypropylene Film Capacitor |
| Brand Name: | MD |
| Operating Temperature: | -40~85 |
| Package Type: | Surface Mount |
| Model Number: | CBB65 |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Product parameters and certification:
SAfety approvals: |
CQC/UL/VDE/TUV/CL |
ApProval standard |
GB/T3667,UL810,EN60252 |
Climatic category |
25/70/21,25/85/21,40/70/21,40/85/21 |
Rated voltage |
150VAC~600VAC(50-60Hz) |
Capacitance range |
3uf~100uf |
Capacitance tolerance |
+_5%(J),+_10%(K),+10%(U),-5%(U) |
Testing voltage | |
BEtween terminals |
2*Un(VAC)/5s |
BEtween terminals and case |
2*Un+1000(VAC)/5S(>=2000VAC) |
Insulation Resistance(20℃) | |
between terminals |
>=2000MΩ,UF(500VDC,5s) |
Tangent of loss angle(20℃) |
<=0.002(100Hz) |
Class of safety protection |
S0/S3 |
FaulT Currency |
10,000AFC(UL810) |
Capacity and sizing
Capacitance(uf) |
250/300VAC |
400-450VAC | ||||
Cylindrical |
Ocal |
Cylindrical |
Ocal | |||
D |
H |
L*W*H |
H |
D |
L*W*H | |
10uf |
40 |
55 |
51.5*31.5*65 |
30 |
60 |
51.5*31.5*65 |
15uf |
40 |
55 |
51.5*31.5*65 |
35 |
60 |
/ |
20uf |
40 |
65 |
51.5*31.5*65 |
40 |
60 |
51.5*31.5*75 |
25uf |
40 |
65 |
51.5*31.5*65 |
40 |
60 |
51.5*31.5*85 |
30uf |
/ |
/ |
/ |
40 |
70 |
71.5*45*75 |
35uf |
40 |
75 |
71.5*45*75 |
45 |
70 |
/ |
40uf |
/ |
/ |
/ |
45 |
70 |
71.5*45*85 |
45uf |
45 |
75 |
71.5*45*75 |
45 |
80 |
/ |
50uf |
45 |
85 |
71.5*45*85 |
45 |
90 |
71.5*45*100 |
60uf |
45 |
95 |
71.5*45*100 |
50 |
90 |
/ |
