| Type: | Whiteboard |
|---|---|
| Brand Name: | grandwon |
| Whiteboard Type: | Interactive Whiteboard |
| Type: | infrared touch |
| Port: | shenzhen |
| Place of Origin: | China (Mainland) |
| Model Number: | GW055-26 |
| Housing Material: | Aluminum frame+Hardware back cover silver/black (optional) |
| Display: | DLED backlight display |
| Display Area: | 1428.48 x 803.52 mm |
| Resolution: | 3840*2160 |
| Contrast Ratio: | 4000:1 |
| IR Touch Screen: | IR Touch 10 point |
| System Version: | Andriod 5.0 |
| OSD: | Chinese,English |
| Built-in Wireless Cast Screen Function: | Support PC, Mobile |
| Internet: | Built-in WIFI / LAN |
Quick Details
Specifications
| Basic Configuration | ||||||
| Housing Material | Aluminum frame+Hardware back cover silver/black (optional) | |||||
| Type | G055EUH | G065EUH | G075EUH | G086EUH | G098EUH | |
| Size | 55inch | 65inch | 75inch | 86inch | 98inch | |
| LCD | Display | DLED backlight display | ||||
| Display Area | 1209.6(H) x 680.4(V) mm | 1428.48 x 803.52 mm | 1650.24 x 928.26 mm | 1895.041065.96 mm | 2156x1212mm | |
| Resolution | 3840*2160 | |||||
| Contrast Ratio | 4000:1 | |||||
| Brightness | 350 CD/ | |||||
| Touch | IR Touch Screen | IR Touch 10 points | ||||
| Andriod System Attribute | CPU | A53 64 bit clocked 1.4Hz 4 cores | ||||
| GPU | Mali450 4 cores | |||||
| RAM | 2G | |||||
| Memory | 32G | |||||
| System Version | Andriod 5.0 | |||||
| Front Interface | PC USB Input | 1 | ||||
| HDMI Input | 1 | |||||
| TOUCH-USB | 1 | |||||
| Andriod USB Input | 1 | |||||
| Front Key | 7Key Control | POWER, SOURCE. MEUN, VOL+, VOL-, ECO. HOME PC | ||||
| Language | OSD | Chinese,English | ||||
| Built-in Wireless Cast Screen Function | Support PC, Mobile | |||||
| Function Interface | ||||||
| Input/Output Interface | LAN Input Interface | 1 | HDMI Input Port | 2 | ||
| VGA Input Port | 1 | PC-AUDIO Input Interface | 1 | |||
| YPBPR Input Interface | 1 | AV Input Interface | 1 | |||
| SD Input | 1 | USB Interface of External Device Touch | 1 | |||
| USB 2.0 | 1 | |||||
| OPS-Optional | CPU/Memory/ hard disk (optional) | Intel i3/4G/128G SSD Intel i5/8G/128G SSD Intel i7/8G/128G SSD | ||||
| Internet | Built-in WiFi / LAN | |||||
| Speaker | Built-in Speaker | 8Ω10W | ||||
| Electrical parameter | ||||||
| Total Power | 300W | 350W | 400W | 500W | 600W | |
| Input Voltage | 100-240V/50-60HZ | |||||
| Size Weight | ||||||
| Net Weight | 35KG | 47KG | 65KG | 82KG | 120KG | |
| Gross Weight (Including carton) | 49KG | 62KG | 80KG | 100KG | 145KG | |
| Product Size | 1320x886x87mm | 1521.8X937.8X101.3mm | 1763.2X1057.6X102.3mm | 2017.4X1207X104.4mm | 2278X1363X99.5mm | |
| Packing Size (Including carton) | 1460x260x965mm | 1648X260X1064mm | 1923X260X1215mm | 2153x260x1352mm | ||
Fty Introduction:
We,Shenzhen Guangwon Industrial Co.,Ltd founded in 2008,In 2018 we listed in the USA Nasdaq stock market,the US Stock Code: GWON.
Grandwon is a high-tech enterprise specializing in Interactive conference board,advertisement player,camera microphone,smart pen and enterprise solutions etc.
They are widely used in many application scenarios,such as office buildings, meeting rooms, shopping malls, hospitals, schools,trainings, subways, banks, hotels and other public areas,etc.
We have built up sales network covering all over the world and efficient after-sales service system in both domestic and overseas.
