Product name: Total New Material HDPE SDR11 Pn16 Plastic Gas Pipe

Outside Diameter: 20mm 630mm

Standard: ISO4437, EN1555, GB/T15558.1-2003, GB/T15558.2-2005

Materials: PE100, PE80

Color: Black with yellow line, Yellow, or as client's requirement.

Fittings offered: All

OEM/ODM: YES

Specification:

20mm-630mm	SDR17.6	SDR11	SDR9
20	2.3	3.0	3.0
25	2.3	3.0	3.0
32	2.3	3.0	3.6
40	2.3	3.7	4.5
50	2.9	4.6	5.6
63	3.6	5.8	7.1
75	4.3	6.8	8.4
90	5.2	8.2	10.1
110	6.3	10.0	12.3
125	7.1	11.4	14.0
140	8.0	12.7	15.7
160	9.1	14.6	17.9
180	10.3	16.4	20.1
200	11.4	18.2	22.4
225	12.8	20.5	25.2
250	14.2	22.7	27.9
280	15.9	25.4	31.3
315	17.9	28.6	35.2
355	20.2	32.3	39.7
400	22.8	36.4	44.7
450	25.6	40.9	50.3
500	28.4	45.5	55.8
560	31.9	50.9	62.5
630	35.8	57.3	70.3

Features of HDPE gas pipe:

1. Non-toxic and health: PE material is non-toxic, tasteless, which has passed through the strict health monitoring.

2. Corrosion resistance: PE belongs to inert materials, can resistance to various chemical media.

3. No leakage: PE pipe is connected by hot fusion melting, its interface strength higher than tube itself.

4. High toughness: Fracture extension rate of PE pipe is more than 500%. as to the uneven settlement of the base, its adaptive ability is very strong and has good aseismic performance.

5. Excellent resistance to quickly crack propagation (RCP) ability, and good flexible and resistance to scratches ability.

6. Good wear resistance: Low wall friction coefficient, small flow resistance, excellent conveying ability.

7. Convenient for construction: Can be used in a variety of trenchless ways of installation.

8. Low system cost: Less maintenance costs than steel pipe to dramatically reduce the project cost.

9. Working life: Anti abrasive, anti-aging, uvioresistant, corrosion resistant, more than 50 years.
