| Brand Name: | Luhua |
|---|---|
| Body Material: | Steel |
| Power: | Hydraulic |
| Structure: | Series Cylinder |
| Standard or Nonstandard: | Standard |
| Model Number: | 2-50KG |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Shandong Luhua container Co.,
Ltd. has been in the forefront of the welded steel cylinder
Manufacturing business in China for nearly to 30 years of experiences in
Servicing both local and export markets.
Technical Aspects of Products
Size Range for LPG cylinders, Valve and accessory products
2 KG. 50 KG.
2kg to 50kg lpg cylinder can be Customized.
Water Capacity(KGS) |
Diameter(mm) |
Overall Height |
Capsule(Bottle) Height |
Test Pressure (Mpa) |
3 |
195 |
260 |
235 |
3.2 |
5 |
249 |
430 |
303 |
3.2 |
6 |
294 |
288 |
248 |
3.2 |
6 |
294 |
310 |
255 |
3.2 |
9 |
294 |
510 |
380 |
3.2 |
10 |
314 |
526 |
376 |
3.2 |
11 |
294 |
554 |
414 |
3.2 |
12.5 |
294 |
582 |
470 |
3.2 |
15 |
314 |
665 |
528 |
3.2 |
15 |
314 |
680 |
528 |
3.2 |
20 |
314 |
823 |
673 |
3.2 |
25 |
314 |
988 |
834 |
3.2 |
45 |
400 |
1110 |
935 |
3.2 |
48 |
400 |
1181 |
996 |
3.2 |
50 |
400 |
1200 |
1015 |
3.2 |
