| Housing Material |
Aluminum frame+Hardware back cover silver/black (optional) |
| Type |
G055EUH |
G065EUH |
G075EUH |
G086EUH |
G098EUH |
| Size |
55inch |
65inch |
75inch |
86inch |
98inch |
| LCD |
Display |
DLED backlight display |
| Display Area |
1209.6(H) x 680.4(V) mm |
1428.48 x 803.52 mm |
1650.24 x 928.26 mm |
1895.041065.96 mm |
2156x1212mm |
| Resolution |
3840*2160 |
| Contrast Ratio |
4000:1 |
| Brightness |
350 CD/ |
| Touch |
IR Touch Screen |
IR Touch 10 points |
| Andriod System Attribute |
CPU |
A53 64 bit clocked 1.4Hz 4 cores |
| GPU |
Mali450 4 cores |
| RAM |
2G |
| Memory |
32G |
| System Version |
Andriod 5.0 |
| Front Interface |
PC USB Input |
1 |
| HDMI Input |
1 |
| TOUCH-USB |
1 |
| Andriod USB Input |
1 |
| Front Key |
7Key Control |
POWER, SOURCE. MEUN, VOL+, VOL-, ECO. HOME PC |
| Language |
OSD |
Chinese,English |
| Built-in Wireless Cast Screen Function |
Support PC, Mobile |
| Function Interface |
| Input/Output Interface |
LAN Input Interface |
1 |
HDMI Input Port |
2 |
| VGA Input Port |
1 |
PC-AUDIO Input Interface |
1 |
| YPBPR Input Interface |
1 |
AV Input Interface |
1 |
| SD Input |
1 |
USB Interface of External Device Touch |
1 |
| USB 2.0 |
1 |
|
|
|
| OPS-Optional |
CPU/Memory/ hard disk (optional) |
Intel i3/4G/128G SSD Intel i5/8G/128G SSD Intel i7/8G/128G SSD |
| Internet |
Built-in WiFi / LAN |
| Speaker |
Built-in Speaker |
8Ω10W |
| Electrical parameter |
| Total Power |
300W |
350W |
400W |
500W |
600W |
| Input Voltage |
100-240V/50-60HZ |
| Size Weight |
| Net Weight |
35KG |
47KG |
65KG |
82KG |
120KG |
| Gross Weight (Including carton) |
49KG |
62KG |
80KG |
100KG |
145KG |
| Product Size |
1320x886x87mm |
1521.8X937.8X101.3mm |
1763.2X1057.6X102.3mm |
2017.4X1207X104.4mm |
2278X1363X99.5mm |
| Packing Size (Including carton) |
1460x260x965mm |
1648X260X1064mm |
1923X260X1215mm |
2153x260x1352mm |
|
