FEATURES
UHF 600-928MHz frequency range
True diversity for maximun range and dropout protection
PLL Synthesized circuit, pre-set 200 selectable frequencies
Super high anti-interference support 10pcs simultaneous use
IR sync downloading the frequency from receiver
LCD display shows status of frequency, AF and RF signal etc
EIA standard 1U rack-mountable metal chassis
up to 500 feet(150m) line-of-sight operating range
Designed for professional stage and performance applications

SPECIFICATION
Comprehensive Performance:
Frequency Range: 600-928MHz
Modulation Mode: FM
Dynamic Range: >100dB
Frequency Response: 60Hz-17KHz±3dB
Total Harmonic Distortion: <0.5% at 1KHz

Signal/Noise Ratio: ≥105dB

Receiver: Frequency Range: 600-928MHz Receive Sensitivity: -110dBm (sinad ≥30dB) Signal/Noise Ratio: >105dB Power Supply: DC12V-18V / 500mA Dimensions: 210*170*44mm Audio Output: 1*XLR socket, 1*6.3mm jack socket

Transmitter: Frequency Range: 600-928MHz RF Power: 10mW Microphone Type: Dynamic Directivity: Cardioid Battery Voltage: 3V (2x1.5V AA Battery) Power Consumption: 8 hours, battery-dependent
