Hot Selling Q195 Q235 Q235B BS 1387 Hot Dipped Galvanized Steel Pipe

Galvanized steel pipes are usually coated with zinc on the outside of low carbon steel. the galvanized layer is usually 20 um thick. the melting point of zinc is 419 C and the boiling point is about 908 C. In welding, zinc melts into liquid and floats on the surface of the molten pool or at the root of the weld. Zinc has a high solid solubility in iron. Zinc liquid will etch weld metal along grain boundary. Low melting point zinc will form "liquid metal embrittlement". At the same time, zinc and iron can form intermetallic brittle compounds. these brittle phases reduce the plasticity of weld metal and cause cracks under tensile stress. If fillet welds, especially T-joints, are most prone to penetrating cracks.



Product specification:

Product name	Hot dipped GalvanizEd Steel Pipe
Technique	Hot rolled
Standard	ASME B36.10, JIS3444,GB/T3091,BS 1387,BS1139,DIN2444
Shape	Round
Specification	OD:21.3mm~660mm WT: 1mm~17.5mm Length:5.8 Mtr/11.8Mtr or Fixed Length
Surface treatment	Bared,Galvanized,Oiled,Color Paint,3PE;Or other Anti-corrosive treatment
Pipe type	Welded steel pipe(round/square/rectangular)



item	Specification		OD(mm)	W.T	Minimum W.T	6MFixed length
	O.D.	Inch				Rice weight	Root weight
1	DN15	1/2	21.3	2.8	2.45	1.36	8.14
2	DN20	3/4	26.9	2.8	2.45	1.76	10.56
3	DN32	1	33.7	3.2	2.8	2.554	15.32
4	DN40	1.25	42.4	3.5	3.06	3.56	21.36
5	DN50	1.5	48.3	3.5	3.06	4.1	24.6
6	DN65	2	60.3	3.8	3.325	5.607	33.64
7	DN80	2.5	76.1	4	3.5	7.536	45.21
8	DN100	3	88.9	4		8.88	53.28
9	DN125	4	114.3	4		11.53	69.18
10	DN150	5	140	4.5		15.942	98.65
11	DN150	6	168.3	4.5		19.27	115.62
12	DN200	8	219.1	6
13	DN200	8	219.1	6.5		36.12	216.7

Product Photos:


Processing:

1.Uncoiling--2 Leveling--3 End cutting--4 End shearing weldling--5 Super coil accumulator --6. Edge cutting--7 Ultrasonic detection--8 Forming--9 Electric induction welding--10.Ultrasonic detection for weld seam--11. Medium frequency heat treatment--12, Air cooling--13. Water cooling --14Sizing--15 Flying cutting--16 Flush-out-- 17. Cropping--18 Flattening,testing--19, Straightening-- 20. End facing and bevelling--21 Hydrodynamic testing--22 Ultrasonic detection for weld seam- 23, Ultrasonic detection for pipe end --24 Visual and dimensions

Inspection--25.Weighting and measuring

Packing & delivery: Packaging Details

1.Bundling with steel strip.

2. Galvanized and packing with plastic wrap.
3. in bulk or containers.
4. Packing in wooden case.
