Quick Details
| Type:
|
Ball
|
| Structure:
|
Deep Groove
|
| Number of Row:
|
Single Row
|
| Seals Type:
|
NBR
|
| Outside Diameter:
|
32-32 mm
|
| Bore Size:
|
12-12 mm
|
| Brand Name:
|
wellbo
|
| Place of Origin:
|
China (Mainland)
|
| Precision Rating:
|
P5
|
| Model Number:
|
6201
|
Specifications
| Technical
Parameter |
| Axial
Clearance |
C0 |
Max Speed |
23,000 rpm |
| Bore diameter |
12mm |
Operating
Temperature |
-35℃-180℃ |
| Outer diameter |
32mm |
Dynamic load rating |
7.28KN |
| Outer ring
Width |
10mm |
Static load rating |
3.1KN |
| Inner ring
Width |
10mm |
Inner ring material |
GCr15 |
| Minimum
Assembly chamfer |
0.6mm |
Outer ring material |
GCr15 |
| Net weight |
0.036kg |
Steel ball material |
GCr15 |
| Packing |
Industrial package |
Retainer material |
SPCC |
| Packing number |
500pcs |
Seal ring material |
NBR |
