| Type: | COB |
|---|---|
| Brand Name: | DETONE |
| Interface Type: | Paralle |
| Resolution: | LCM |
| application: | Industrial machine, medical instrument, apparatus and meters |
| Model Number: | LCMD12864-5 |
Quick Details
Specifications
2. COB type,
3. Parallel interface optional
4. 3.3V.5Vpower supply
5. STN-yellow or blue. LED backlight
3. Parallel interface optional
4. 3.3V.5Vpower supply
5. STN-yellow or blue. LED backlight
| Viewing Angle | 6 O' clock |
| LCD Type | STN-Blue or STN-YELLOW |
| Backlight | YELLOW or White LED backlight |
| Driver IC | S6B0064 |
| Power supply | 3.3V or 5V |
| Interface | Parallel |
| Operating Temp | -20o C~70o C |
| Storage Temp | -30o C~80o C |
