| Brand Name: | Kaiyuan |
|---|---|
| Refractoriness (Degree): | 1770°< Refractoriness< 2000° |
| Al2O3 Content (%): | 70% |
| Material: | Alumina Block |
| Shape: | Brick |
| Model Number: | SK38 |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Characteristics of this series products are as follow:
the brick is made from sintered special grade clay, pressed by high pressure and sintered at high temperature, with excellent spalling resistance, alkali,sodium,sulfur,chlorine and alkalic salt corrosion. Low thermal conductivity, a better and ideal choice for steel industry.
the brick is made from sintered special grade clay, pressed by high pressure and sintered at high temperature, with excellent spalling resistance, alkali,sodium,sulfur,chlorine and alkalic salt corrosion. Low thermal conductivity, a better and ideal choice for steel industry.
Items |
Fireclay brick | High alumina brick | ||||||
| SK30 | SK32 | SK34 | SK35 | SK36 | SK37 | SK38 | SK40 | |
| Al2O3,% ≥ | 30 | 32 | 38 | 45 | 55 | 65 | 70 | 82 |
| Fe2O3,%≤ | 2.5 | 2.5 | 2 | 2 | 2 | 2 | 2 | 2 |
| Refractoriness,SK | 30 | 32 | 34 | 35 | 36 | 37 | 38 | 40 |
| Refractoriness,C | 1670 | 1710 | 1750 | 1770 | 1790 | 1820 | 1850 | 1920 |
| Refractiriness under load,0.2Mpa | 1250 | 1350 | 1370 | 1420 | 1450 | 1480 | 1530 | 1600 |
| Apparent porosity,% ≤ | 22-26 | 20-24 | 20-22 | 18-20 | 20-23 | 20-23 | 20-22 | 18-20 |
| Bulk density,g/cm3 | 1.9-2.0 | 1.95-2.1 | 2.1-2.2 | 2.15-2.22 | 2.25-2.4 | 2.3-2.5 | 2.4-2.6 | 2.5-2.7 |
| Cold crushing strength,Mpa ≥ | 20 | 25 | 30 | 40 | 45 | 50 | 60 | 70 |
