| Type: | Screw |
|---|---|
| Conductor Size: | >30 AWG |
| Number of Contacts: | 21 - 30 |
| Brand Name: | WBR |
| Wire range: | 0.2-35mm |
| Model Number: | UK35N |
| Place of Origin: | China (Mainland) |
| colour: | Gray |
Quick Details
Specifications
| Model No. | JUK 35N |
| Color | Grey, Blue, other color can be customized |
| Length/Height/Wide (mm) | 42.5/42/16 |
| Connection method | Screw connection |
| Material | Flame resistant Nylon PA66, Nickel plated brass conductor |
| Rated Voltage/Current | 800V/24A |
| CRoss section, solid/soft Cable | 0.14-35mm2 / 0.14-35mm2 |
| Conductor Size | 24-12 AWG |
| Mounting Type | DIN Rail NS 35 |
| Standard | IEC 60947-7-1 |
| LOGO | WonkeDQ, LOGO can be customized |
| Packing Detail | 4.32g/PC, 100PCS/BOX,1500PCS/CTN |
| Certification | CE/RoHS/CQC/ISO 9001 |
