Basic information:
Chemical Name: Perfluoro (2-methyl-3-pentanone)

Synonyms: Noah5112; Noah1230; FK-5-1-12; Dodecafluoro-2-methylpentan-3-one; C6 Fluoroketone.
Molecular Formula: C₆F₁₂O
Molecular Weight: 316.045

CAS No.: 756-13-8

EC NO.: 436-710-6

Chemical code: FK-5-1-12


Introduction:

at Normal temperature, Noah5112 is colorless, transparent and insulating liquid. It Is the novel environmental harmonic and clean extinguishing agent. Noah5112 is Listed in standard documents such as ISO14520-2006 Physical Characteristics of Gas Extinguishing System, the System Design, NFPA2001 Design Specification of Clean Gas Extinguishing System, and the application-design of the product is Normatively described.



Noah5112 Extinguishing agent is a novel substitution of halon extinguishing agent. It helps engineers and facility managers meet environmental regulations while helping ensure the Safety of people, reduce risks and preserve business operations with minimal Downtime. It features zero ozone depletion potential (ODP) and a global warming Potential (GWP) of less than 1. Noah5112 also has the largest safety margin for Use in occupied spaces of all clean agents. It effectively extinguishes fire Faster than inert gas or water mist systems, requires less volume of fluid and Is safe for use with electronics.


Physical properties of Noah5112

Property	Value
Molecular mass	316.045
Boiling point at 1atm	49.2℃
Freezing point	-108℃
Critical temperature	168.7℃
Critical pressure	18.65 Bar
Critical density	639.1 kg/m3
Heat of at boiling point	88.0 kJ/kg
Liquid Viscosity @25℃	0.524 cp
Solubility of water in Noah5112 @25℃
Specific heat,Liquid@25℃	1.013 kJ/kg℃
Saturated liquid density(25℃)	1.60 g/ml
Vapor pressure(25℃)	0.404 bar
Insulating property (110k)	3.8mA(Standard leakage current≤10mA)
Dielectric strength (kV)	74.6 kV (Test distance 3mm)
ODP	0
GWP	1.0
ATL (year)	0.014
