| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Brand Name: | JUNENG |
| Automatic: | Yes |
| Blow Moulding Type: | Extrusion Blow Moulding |
| Condition: | New |
| Warranty: | 1 year |
| Certification: | ISO9001 CE |
| Weight: | 35ton |
| Dimension(L*W*H): | 7.8*2.9*5.4 |
| Power(W): | 35 |
| Voltage: | 3 phase, 380v |
| Model Number: | JN-260L |
| Place of Origin: | China (Mainland) |
| Application: | |
| size of mould: | 1300-1600 |
| out of HDPE: | 320-380kg/hr |
Quick Details
Specifications
1.Brief Introduction:
2.Techincal parameters:
Max. Product Volume
L
250 Dry cycle
PC/H
300 Screw diameter
MM
120 Screw L/D ratio
L/D
28-32 Screw motor power
KW
90-132 Screw heating capacity
KW
22 No. of heating zone
Zone
6 Output of HDPE
KG/H
320-380 Oil pump driver power
KW
45 Clamping force
KN
900 Mold stroke
MM
720-1800 Size of mold(W*H)
MM
1300x1600 Moving distance
MM
600 Max. Die diameter(W*H)
MM
15 Die heat capacity
KW
22 Blowing pressure
MPA
0.8 Air volume
M3/Min
3.0 Cooling water pressure
MPA
0.3 Water consumption
L/Min
250 Weight of machine
Ton
35 Size of machine
M
7.8*2.9*5.4
3.Performance features:
