| Interface Type: | PCI Express |
|---|---|
| Transmission Rate: | 10/100/1000Mbps |
| Type: | Wireless |
| Application: | Server |
| Products Status: | Stock |
| Place of Origin: | China (Mainland) |
| Model Number: | LRUA5254 |
| Brand Name: | Linkreal |
| Certification: | Ce, Rohs |
| Kind: | Internal |
| Connector: | 4*RS-232 Connector |
| Cable: | DB9 9Pin Flat Data Cable |
| Support: | 4*RS-232 Connector |
| Host Bus: | PCIe 2.0 x1 |
Quick Details
Specifications
Product LRUA5254 uses EXAR 17v354 chipset solution to expand 4 RS-232 Serial ports(DB9 Pin) through M.2 slot. It can connect 4 RS-232 Serial devices at the same time to provide modulation and control signals so to ensure the compatibility of peripheral equipments. It provides cost-effective, high speed and stable solutions to customers.
Spec:
Support PCIe2.0 Gen 1
Adopt M.2 B Key+M Key connector, small in size with excellent transmission performance
4 standard RS-232 serial ports, each can reach to 921.6Kbps
Multi-port serial devices communication through 4 DB9 Pin cables
256Byte of TX and RX FIFO, on-board hardwares, softwares flow control and burst datagram
Support Windows, XP, Vista, Linux and so on
Application:
Widely used in POS Systems, Serial Port Net, Printer, Industrial Control, Automation Systems and other Serial Devices.
