| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Brand Name: | JUNENG |
| Automatic: | Yes |
| Blow Moulding Type: | Extrusion Blow Moulding |
| Condition: | New |
| Warranty: | 1 year |
| Certification: | ISO9001 CE |
| Weight: | 20 |
| Dimension(L*W*H): | 5*3.8*3 |
| Power(W): | 77 |
| Voltage: | 3 phase, 380v |
| Model Number: | JN-100U |
| Place of Origin: | China (Mainland) |
| Application: | Bottle |
| Volume: | 20L |
| Dry cycle: | 500*2 |
| Clamping force: | 190KN |
| Out of HDPE: | 200-280kg/hr |
| oil pump of driver motor: | 30kw |
| mould stroke: | 350-380 |
| size of mould: | 650*700 |
| air volume: | 2-3min |
| blowing pressure: | 0.8mpa |
| water consumption: | 90L/MIN |
Quick Details
Specifications
the following example is for you reference.
1.Brief Introduction:
2.Techincal parameters:
3.Performance features:
Max. Product Volume
L
20L/1 Dry cycle
PC/H
500x2 Screw diameter
MM
100 Screw L/D ratio
L/D
25 Screw motor power
KW
45-55 Screw heating capacity
KW
8.5-10 No. of heating zone
Zone
4 Output of HDPE
KG/H
200-280 Oil pump driver power
KW
30 Clamping force
KN
190 Mold stroke
MM
350-800 Size of mold(W*H)
MM
650x700 Moving distance
MM
700 Max. Die diameter(W*H)
MM
260 Die heat capacity
KW
5.0-6.0 Blowing pressure
MPA
0.8 Air volume
M3/Min
2-3 Cooling water pressure
MPA
0.7 Water consumption
L/Min
90 Weight of machine
Ton
20 Size of machine
M
5x3.8x3
