| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Brand Name: | JUNENG |
| Automatic: | Yes |
| Blow Moulding Type: | Extrusion Blow Moulding |
| Condition: | New |
| Warranty: | 1 year |
| Certification: | ISO9001 CE |
| Weight: | 10.2ton |
| Dimension(L*W*H): | 3.5*3*2.6 |
| Power(W): | 10.2 |
| Voltage: | 3 phase, 380v |
| Model Number: | JN-2S5L-DT |
| Place of Origin: | China (Mainland) |
| Application: | Bottle |
| Volume: | max. 5L |
| Dry cycle: | 700*2 |
| Clamping force: | 68KN |
| Out of HDPE: | 70-85kg/hr |
| oil pump of driver motor: | 11kw |
| mould stroke: | 148-508 |
| size of mould: | 370*390 |
| air volume: | 0.6 |
| blowing pressure: | 0.6-0.8mpa |
| water consumption: | 65L/min |
Quick Details
Specifications
the following example is for you reference.
1.Brief Introduction:
2.Techincal parameters:
Max. Product Volume L 5L/1 Dry cycle PC/H 700*2 Screw diameter MM 70+40+25 Screw L/D ratio L/D 25 Screw motor power KW 22+7.5+1.1 Screw heating capacity KW 5.4-8.2 No. of heating zone Zone 3 Output of HDPE KG/H 70-85 Oil pump driver power KW 11 Clamping force KN 68 Mold stroke MM 148-508 Size of mold(W*H) MM 370x390 Moving distance MM 420 Max. Die diameter(W*H) MM 160 Die heat capacity KW 3.5-4.3 Blowing pressure MPA 0.6-0.8 Air volume M3/Min 0.6 Cooling water pressure MPA 0.4 Water consumption L/Min 65 Weight of machine Ton 10.2 Size of machine M 3.5x3x2.6
3.Performance features:
