| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Brand Name: | JUNENG |
| Automatic: | Yes |
| Blow Moulding Type: | Extrusion Blow Moulding |
| Condition: | New |
| Warranty: | 1 year |
| Certification: | ISO9001 CE |
| Weight: | 8 ton |
| Dimension(L*W*H): | 4*2.86*2.5 |
| Power(W): | 11 |
| Voltage: | 3 phase, 380v |
| Model Number: | JN-80U |
| Place of Origin: | China (Mainland) |
| Application: | Bottle |
| Volume: | 1L/3 |
| Dry cycle: | 700*2 |
| Clamping force: | 100KN |
| Out of HDPE: | 100-120kg/hr |
| oil pump of driver motor: | 11kw |
| mould stroke: | 200-500mm |
| size of mould: | 410*400 |
| air volume: | 0.6-0.8mpa |
| blowing pressure: | 0.8min |
| water consumption: | 70L/min |
Quick Details
Specifications
the following example is for you reference.
1.Brief Introduction:
2.Techincal parameters:
Max. Product Volume
L
1L/3 Dry cycle
PC/H
700x2 Screw diameter
MM
80 Screw L/D ratio
L/D
24-26 Screw motor power
KW
30 Screw heating capacity
KW
5.5 No. of heating zone
Zone
4 Output of HDPE
KG/H
100-120 Oil pump driver power
KW
11 Clamping force
KN
100 Mold stroke
MM
200-500 Size of mold(W*H)
MM
410x400 Moving distance
MM
480 Max. Die diameter(W*H)
MM
160 Die heat capacity
KW
3.5-4.3 Blowing pressure
MPA
0.6-0.8 Air volume
M3/Min
0.6 Cooling water pressure
MPA
0.3 Water consumption
L/Min
60 Weight of machine
Ton
8 Size of machine
M
4x2.86x2.5
3.Performance features:
